IoC Basics: XML and Annotation Combined Configuration

XML and Annotation Combined Method

Important notes:

In actual enterprise development, pure XML mode is rarely used anymore
Introducing annotation functionality does not require introducing additional JARs
In XML + annotation combined mode, the XML file still exists, so the Spring IoC container still starts by loading XML
Which Bean definitions need to be written in XML and which use annotations

Simply put: Bean definitions for third-party JARs are in XML, while Beans you develop yourself use annotation method.

XML Tags and Annotation Correspondence

XML Tag	Annotation
`<bean>`	`@Component`, `@Repository`, `@Service`, `@Controller`
`<property>`	`@Value`
`<constructor-arg>`	Constructor injection

DI Dependency Injection Annotation Implementation

It is recommended to use @Autowired, which is an annotation provided by Spring, using a byType injection strategy:

public class WzkTransferServiceImpl {
    @Autowired
    private WzkAccountDao wzkAccountDao;
}

As shown in the code above, this assembly will go to the Spring container to find the class of type AccountDao and inject it. This creates a problem: when one type has multiple Bean values, it becomes impossible to choose which one to inject. At this point, we need to use the @Qualifier annotation together.

@Qualifier tells Spring which object to inject:

public class WzkTransferServiceImpl {
    @Autowired
    @Qualifier(name="jdbcWzkAccountDaoImpl")
    private WzkAccountDao wzkAccountDao;
}

Of course, we can also use the @Resource annotation provided by JDK, which defaults to byName auto-injection:

public class WzkTransferService {

    @Resource
    private AccountDao accountDao;

    @Resource(name="studentDao")
    private StudentDao studentDao;

    @Resource(type="TeacherDao")
    private TeacherDao teacherDao;

    @Resource(name="manDao",type="ManDao")
    private ManDao manDao;

}

Important notes:

If both name and type are specified, search for the unique matching Bean in the Spring context for assembly
If name is specified, search in the context for the Bean matching the name (id) for assembly; throw exception if not found
If type is specified, search in the context for the unique Bean matching the type for assembly; throw exception if not found or multiple found
If neither name nor type is specified, automatic byName assembly is used

Important: Resource has been removed in JDK 11. If you need to use it, you need to introduce the JAR separately:

<dependency>
 <groupId>javax.annotation</groupId>
 <artifactId>javax.annotation-api</artifactId>
 <version>1.3.2</version>
</dependency>

applicationContext.xml Configuration

Content as follows:

<?xml version="1.0" encoding="UTF-8"?>
<beans  xmlns="http://www.springframework.org/schema/beans"
        xmlns:context="http://www.springframework.org/schema/context"
        xmlns:aop="http://www.springframework.org/schema/aop"
        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:schemaLocation="
        http://www.springframework.org/schema/beans
        https://www.springframework.org/schema/beans/spring-beans.xsd
        http://www.springframework.org/schema/context
        https://www.springframework.org/schema/context/spring-context.xsd
        http://www.springframework.org/schema/aop
        https://www.springframework.org/schema/aop/spring-aop.xsd
">

</beans>

web.xml Configuration

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_3_1.xsd"
         version="3.1">
    <context-param>
        <param-name>contextConfigLocation</param-name>
        <param-value>classpath:applicationContext.xml</param-value>
    </context-param>
    <listener>
        <listener-class>org.springframework.web.context.ContextLoaderListener</listener-class>
    </listener>
</web-app>

Configuration Transformation

Next, we transform the pure XML mode code to annotation + XML mode, freeing up some XML.

For example, in pure XML mode, we wrote:

<!-- Configure Bean -->
<bean id="wzkTransferService" class="wzk.service.impl.WzkTransferServiceImpl">
    <constructor-arg name="wzkAccountDao" ref="wzkAccountDao"></constructor-arg>
</bean>

The purpose is to let Spring take over our Bean. At this point, we can remove all these Bean configurations and use annotations to satisfy our Bean management.

At this point, we remove the Bean XML configuration and add annotations to the Beans that need to be managed by Spring, along with DI management. But at this time, Spring doesn’t know which objects to process, so we need to tell Spring which packages to scan:

<context:annotation-config/>
<context:component-scan base-package="wzk"/>

Code Transformation Example

JdbcWzkAccountDaoImpl

Here we add annotation and ID management, partially as follows:

@Component
public class JdbcWzkAccountDaoImpl implements WzkAccountDao {

    @Autowired
    private WzkConnectionUtils wzkConnectionUtils;

}

WzkTransferServiceImpl

@Component
public class WzkTransferServiceImpl implements WzkTransferService {

    @Autowired
    private WzkAccountDao wzkAccountDao;

}

WzkServlet (Important!!)

Here it should be noted that technically, we should also write @Component and @Autowired on WzkServlet to inject our WzkTransferService, but in reality, @Component and @Servlet annotations conflict.

@WebServlet is a Servlet annotation, managed by Tomcat
@Component is a Spring annotation, managed by Spring

At this point, we are required not to use the Component annotation here. We need to use WebApplicationContext to handle this:

@WebServlet(name="wzkServlet", urlPatterns = "/wzkServlet")
public class WzkServlet extends HttpServlet {

    private WzkTransferService wzkTransferService;

    @Override
    public void init() throws ServletException {
        ApplicationContext context = WebApplicationContextUtils
                .getWebApplicationContext(getServletContext());
        this.wzkTransferService = context.getBean(WzkTransferService.class);
    }

    @Override
    protected void doGet(HttpServletRequest req, HttpServletResponse resp)
            throws ServletException, IOException {
        try {
            wzkTransferService.transfer("1", "2", 100);
        } catch (Exception e) {
            e.printStackTrace();
            System.out.println("=== transfer error ====");
        }
        resp.setContentType("application/json;charset=utf-8");
        resp.getWriter().print("=== WzkServlet doGet ===");
    }
}

Utility Class

For some utilities we use that have dependency relationships, we also let Spring manage them:

@Component
public class WzkConnectionUtils {

    private final ThreadLocal<Connection> threadLocal = new ThreadLocal<>();

}

Summary

Through the XML and annotation combined method, we can:

Reduce XML configuration: Let custom Beans be managed by annotations
Retain XML configuration: For managing third-party Beans
Component scanning: Use <context:component-scan> to specify packages to scan
Servlet special handling: Because @Component conflicts with @WebServlet, need to use WebApplicationContextUtils to manually get Beans
