RabbitMQ Installation and Container Quick Start: Erlang, RPM

TL;DR

Scenario: Using RPM for RabbitMQ production deployment on RHEL systems (CentOS/RockyLinux), while using Docker Compose for quick learning.
Conclusion: Key risks are Erlang/RabbitMQ version compatibility and package source consistency; followed by ports, plugins, user permissions and security baseline.
Output: Deployable installation path, version matrix writing and high-frequency error quick reference for production deployment and troubleshooting.

RabbitMQ Installation

Service Installation (Production Recommended)

Environment Preparation

Operating System Environment:
- Supports CentOS 7/8, RockyLinux 8/9 and other RHEL-based distributions
- Using minimal installation recommended to reduce unnecessary software conflicts
Erlang Environment Requirements:
- RabbitMQ is a message middleware running on Erlang VM (BEAM)
- Must pre-install compatible version of Erlang runtime
- Recommended version not lower than Erlang 23.x
System Dependency Packages:
- socat: For inter-cluster communication
- logrotate: Log rotation management
- openssl: Secure communication support
- Other build toolchain (gcc, make, etc.)

socat Installation

yum install socat -y

Erlang Installation

Download Erlang RPM package:

https://github.com/rabbitmq/erlang-rpm/releases/download/v23.0.2/erlang-23.0.2-1.el7.x86_64.rpm

Upload file to server and execute installation:

rpm -ivh erlang-23.0.2-1.el7.x86_64.rpm

RabbitMQ Installation

Download RabbitMQ:

https://github.com/rabbitmq/rabbitmq-server/releases/download/v3.8.4/rabbitmq-server-3.8.4-1.el7.noarch.rpm

After uploading to server, install:

rpm -ivh rabbitmq-server-3.8.4-1.el7.noarch.rpm

Enable Plugins

rabbitmq-plugins enable rabbitmq_management

Several Ways to Start RabbitMQ Service

1. Using systemctl (Recommended for Production)

systemctl start rabbitmq-server

This is the most standard startup method, applicable to Linux systems using systemd
Automatically handles service dependencies and logging

2. Direct Executable (Suitable for Development)

rabbitmq-server

Runs in foreground, convenient for viewing real-time logs
Press Ctrl+C to stop service
Typical use case: Quick startup during local development testing

3. Background Daemon Mode

rabbitmq-server -detached

Adding -detached parameter runs service in background
Does not occupy current terminal
Stopping service requires rabbitmqctl stop

# Check service status
systemctl status rabbitmq-server

# Set开机自启
systemctl enable rabbitmq-server

# Stop service
systemctl stop rabbitmq-server

Add User

rabbitmqctl add_user root 123456

Add Permissions

rabbitmqctl set_permissions root -p / ".*" ".*" ".*"

Set User Tags (RabbitMQ User Permission Management)

rabbitmqctl set_user_tags root administrator

Detailed Explanation:

This command sets tags for RabbitMQ user, adding administrator tag to user root
Tag type explanation:
- administrator: Admin permissions, has all operation permissions
- monitoring: Monitoring permissions, can view all information but cannot modify
- policymaker: Policy-making permissions, can manage virtual host policies
- management: Basic management permissions, can use management plugin
Related commands:
- View user tags: rabbitmqctl list_users
- Clear user tags: rabbitmqctl clear_user_tags username

Container Installation (Learning Recommended)

Docker Compose

Quickly start service via container:

services:
  rabbitmq:
    image: rabbitmq:3.8.4-management
    container_name: rabbitmq-3.8
    restart: unless-stopped
    ports:
      - "5672:5672"      # AMQP
      - "15672:15672"    # Management interface
    environment:
      RABBITMQ_DEFAULT_USER: admin
      RABBITMQ_DEFAULT_PASS: secret
    volumes:
      - rabbitmq_data:/var/lib/rabbitmq
volumes:
  rabbitmq_data:

Start Service

docker compose up -d

Access Service

Access port 15672, fill in username and password from the file:

Username: admin
Password: secret

RabbitMQ Management Commands

Service Start and Stop

Foreground Start

rabbitmq-server

Background Start

rabbitmq-server -detached

Stop Service

rabbitmqctl stop

Application Management

Application Control

# Start application
rabbitmqctl start_app

# Stop application (without stopping Erlang VM)
rabbitmqctl stop_app

Node Status Check

rabbitmqctl status

Queue Management

View Queues

rabbitmqctl list_queues

Virtual Host Management

rabbitmqctl list_vhosts

Plugin Management

# List all available plugins
rabbitmq-plugins list

# Enable specified plugin
rabbitmq-plugins enable <plugin-name>

# Disable specified plugin
rabbitmq-plugins disable <plugin-name>

User Management

# Add new user
rabbitmqctl add_user username password

# List all users
rabbitmqctl list_users

# Delete user
rabbitmqctl delete_user username

# Clear permissions
rabbitmqctl clear_permissions -p vhostpath username

Advanced Usage Examples

View Queue Details

rabbitmqctl list_queues name messages messages_ready messages_unacknowledged

Create Virtual Host and Set Permissions

# Create vhost
rabbitmqctl add_vhost /my_vhost

# Set user permissions
rabbitmqctl set_permissions -p /my_vhost username ".*" ".*" ".*"

View Connection Information

rabbitmqctl list_connections

View Channel Information

rabbitmqctl list_channels

Error Quick Reference

Symptom	Root Cause	Diagnosis	Fix
`rpm -ivh rabbitmq-server-...rpm` reports missing dependencies	socat/openssl and other dependencies not installed or version mismatch	`rpm -qpR package-name.rpm`	Install dependencies first; unify repository source
RabbitMQ version number inconsistent	Documentation version number inconsistency causing misoperation	Compare download link with installed filename	Unify version number
Startup fails,提示 Erlang version incompatible	Erlang/OTP and RabbitMQ version range mismatch	`erl -version`; startup logs	Select Erlang version according to official compatibility matrix
`systemctl start rabbitmq-server` fails	service unit/permission/data directory issue	`systemctl status` + `journalctl -u rabbitmq-server`	Fix based on logs
`rabbitmq-plugins enable` fails	Node not running, plugin directory not writable	`rabbitmqctl status`	Ensure service started normally first
Access 15672 fails	Port not listening/firewall not opened/plugin not enabled	`ss -lntp\|grep 15672`	Check firewall and plugin status
Login to management console fails after adding user	User permissions/tags not set or vhost permissions missing	`rabbitmqctl list_users`	Execute `set_permissions` and `set_user_tags` together
Permissions set successfully but business still rejects	Used non-`/` vhost	Management console check vhost	Set permissions for actual vhost
Docker Compose data lost after startup	Volume not mounted or volume name changed	`docker volume ls`	Keep volume configuration
Default account/weak password security risk	admin/secret, root/123456 are guessable credentials	Configuration and command sections	Production change to strong password and limit exposure
