Build MQ Prototype with BlockingQueue: Producer-Consumer Gap

TL;DR

• Scenario: Implement a minimal runnable message model with queue buffering and async decoupling using Java concurrency
• Conclusion: BlockingQueue can explain MQ core interactions, but lacks persistence, ACK, retry, cluster, observability
• Output: A runnable Producer/Consumer Demo + enterprise gap list

Version Matrix

Project	Status	Description
JDK Version	Unverified	BlockingQueue/ArrayBlockingQueue logic consistent across JDK 8/11/17
Queue Implementation	Verified	ArrayBlockingQueue<>(20) clearly defined

Message Middleware - Basic Concepts

Message-Oriented Middleware (MOM) is a core component for implementing asynchronous communication in distributed system architecture.

Typical Features:

1. Async Communication Mechanism: Uses “fire-and-forget” pattern
2. Message Persistence: Ensures messages not lost through disk storage or replication mechanism
3. Protocol Support: Usually supports AMQP, MQTT, STOMP and other standard protocols
4. Message Routing: Provides flexible routing strategies

Mainstream Implementation Comparison:

System	Throughput	Latency	Persistence
RabbitMQ	Medium	Low	Supported
Kafka	High	Medium	Strong support
RocketMQ	High	Low	Supported

Custom Message Middleware

Producer

public class WzkProducer implements Runnable {
    private final BlockingQueue<Good> blockingQueue;

    @Override
    public void run() {
        try {
            while (true) {
                Thread.sleep(2000);
                if (blockingQueue.remainingCapacity() > 0) {
                    Good good = Good.builder()
                            .id(UUID.randomUUID().toString())
                            .type("food")
                            .build();
                    blockingQueue.add(good);
                }
            }
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

Consumer

public class WzkConsumer implements Runnable {
    private final BlockingQueue<Good> blockingQueue;

    @Override
    public void run() {
        try {
            while (true) {
                Thread.sleep(1000);
                Good good = blockingQueue.take();
                System.out.println("Consumed food: " + good);
            }
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

Main

public class WzkMain {
    public static void main(String[] args) throws Exception {
        BlockingQueue<Good> blockingQueue = new ArrayBlockingQueue<>(20);
        WzkProducer wzkProducer = new WzkProducer(blockingQueue);
        WzkConsumer wzkConsumer = new WzkConsumer(blockingQueue);
        new Thread(wzkProducer).start();
        Thread.sleep(10_000);
        new Thread(wzkConsumer).start();
    }
}

Production Environment Gaps

Key Issues to Consider:

1. Message Persistence: Need to support persistent message storage to prevent message loss when system crashes

2. Message Reliability Guarantee:

   • Send acknowledgment mechanism: Implement ACK/NACK mechanism
   • Consume acknowledgment mechanism: Consumer needs explicit acknowledgment after processing

3. High Concurrency Processing: Need to support horizontally scalable cluster architecture

4. System Reliability:

   • Failover mechanism: Primary-secondary switch, automatic recovery
   • Multi-datacenter deployment: Multi-active disaster recovery solution
   • Monitoring alerts: Complete health checks and monitoring system

5. Flow Control:

   • Rate limiting mechanism: Token bucket or leaky bucket algorithm
   • Circuit breaker degradation: Prevent system overload

Error Quick Reference

Symptom	Root Cause	Fix
Producer throws exception or thread exits when queue is full	Using blockingQueue.add() throws exception when queue full	Change to put() or offer(timeout)
Consumer take() blocks appearing “stuck”	take() blocks when queue empty	For graceful shutdown: use poll(timeout)
Cannot shutdown gracefully	while(true) infinite loop	Use while(!Thread.currentThread().isInterrupted())
Data reliability is 0	In-memory queue, no persistence, no replica, no replay	Need WAL mechanism
Duplicate consumption/message loss uncontrollable	No ACK, no retry, no idempotency, no dead letter	Introduce ACK + retry + DLQ design
