Guava Cache: From ConcurrentHashMap to LocalCache Structure

TL;DR

• Scenario: Guava Cache is widely used in production, but many lack understanding of LocalCache specific behavior
• Conclusion: Guava achieves thread-safe local cache through LocalCache+Segment structure, reference queues, and access/write queues
• Output: Core structure analysis + eviction mechanism explanation + common issue troubleshooting

Fundamental Differences: Guava Cache vs ConcurrentHashMap

Feature	ConcurrentHashMap	Guava Cache
Lifecycle	Permanent storage, requires explicit remove	Supports automatic expiration and eviction
Eviction Mechanism	None	Capacity/time/reference eviction
Applicable Scenario	Long-term configuration information	High-frequency access temporary data

LocalCache Core Structure

1. Segment-based Locking Design

• LocalCache internally maintains Segment array
• Controlled by concurrencyLevel parameter (default 4)
• Read operations are lock-free (volatile), write operations require Segment lock

2. Five Queue Mechanism

• keyReferenceQueue: Tracks GC-recycled weak reference keys
• valueReferenceQueue: Tracks GC-recycled weak/soft reference values
• recencyQueue: Temporarily records recently accessed entries
• writeQueue: Ordered by write time (LRU)
• accessQueue: Ordered by access time

3. Data Table Structure

AtomicReferenceArray<ReferenceEntry<K,V>> table: Hash table storage

ReferenceEntry contains: key, hash, valueReference, next fields

Eviction Mechanism

1. Capacity-based Eviction

Uses LRU (Least Recently Used) strategy for eviction

2. Timed Eviction

• expireAfterAccess: Expires after access
• expireAfterWrite: Expires after write

3. Reference-based Eviction

Supports weak reference keys, weak reference values, soft reference values

Lazy Eviction Mechanism

Guava Cache uses lazy eviction and does not actively scan the entire cache:

1. During get() operation: Check if the entry corresponding to the key has expired, remove if expired
2. During put() operation: Check if cache size exceeds limit, trigger LRU eviction if so

Common Issue Troubleshooting

Symptom	Root Cause	Fix
Memory continuously grows	Not set maximumSize	Configure maximumSize/maximumWeight
Low hit rate	Expiration time too short	Adjust expireAfterAccess/Write
Memory surges after no traffic	Lazy eviction not triggered	Periodically call cache.cleanUp()
Data loss caused by weak references	GC recycling too frequent	Use weak references only when memory pressured
