Guava Cache: concurrencyLevel and refreshAfterWrite in Pr...

TL;DR

• Scenario: Using Guava Cache for local caching in high-concurrency Java services, while needing to control refresh latency and memory usage
• Conclusion: Reasonably set concurrencyLevel + refreshAfterWrite, and understand LoadingCache’s single-key locking semantics
• Output: Concurrency parameter selection guide, refresh blocking behavior understanding framework

Version Matrix

Component / Capability	Version / Range	Verified
JDK 8	1.8.x	Yes
JDK 11	11.x	Yes
JDK 17	17.x	Yes
Guava Cache	23.x–32.x+	Yes

Concurrency Settings

Concurrency Level Parameter Details

1. concurrencyLevel specifies the number of segment locks used internally by the cache (default value is 4)
2. Each segment independently manages a portion of cache entries, different segments can operate concurrently
3. Reasonably setting this value can significantly reduce thread competition (recommended to set to 1.5x estimated concurrent thread count)

Underlying Implementation Principle

Uses striped locking technology to divide the entire cache into multiple Segments:

Cache<String, Object> cache = CacheBuilder.newBuilder()
    .concurrencyLevel(8)  // Set to 8 segments
    .maximumSize(1000)
    .build();

Performance Optimization Suggestions

• Low concurrency scenario (<4 threads): Use default value
• Medium concurrency (4-16 threads): Recommended to set to 8-16
• High concurrency scenario (>16 threads): Need to adjust based on actual pressure testing

Update Locking

Guava Cache provides refreshAfterWrite configuration item for timed data refresh:

1. Background will start an async thread to fetch latest data from source
2. During refresh, all requests for that cache entry will be blocked, default blocking time is 1 minute
3. Only one request will actually execute the source fetch during refresh

CacheBuilder.newBuilder()
    .refreshAfterWrite(5, TimeUnit.MINUTES)
    .build(new CacheLoader<String, Object>() {
        @Override
        public Object load(String key) throws Exception {
            return fetchDataFromDB(key);
        }
    });

Note:

• Unlike expireAfterWrite, refreshAfterWrite does not automatically remove expired data

Custom LRU

class LRUCache<K,V> extends LinkedHashMap<K, V> {
    private final int limit;

    public LRUCache(int limit) {
        super(limit, 0.75f, true);
        this.limit = limit;
    }

    @Override
    protected boolean removeEldestEntry(Map.Entry<K, V> eldest) {
        return size() > limit;
    }
}

Error Quick Reference

Symptom	Root Cause	Fix
Cache hit rate deteriorates as concurrent threads increase	concurrencyLevel set too high	Keep concurrencyLevel near estimated concurrent thread count
Believing expired data will be automatically cleared after configuring refreshAfterWrite	Confusing refreshAfterWrite with expireAfterWrite	Also configure expireAfterWrite or explicit invalidate
Read blocked during peak hours	Load/source logic too slow	Optimize source logic, add timeout and degradation
