PageHelper

MyBatis uses third-party plugins to extend functionality. The pagination assistant PageHelper encapsulates complex pagination operations. You can obtain pagination-related data in a simple way. PageHelper is a pagination plugin for MyBatis or MyBatis-Plus that provides easy-to-use pagination functionality. It intercepts SQL queries and automatically adds pagination conditions during queries to implement data pagination queries.

Basic Features

PageHelper helps us automatically perform pagination queries when using MyBatis, avoiding manually writing complex pagination logic. Through the interceptor approach, it dynamically passes pagination parameters into SQL statements during query execution and obtains pagination results by setting pagination objects.

Working Principles

The core functionality of PageHelper is to modify SQL through interceptors and add pagination parameters. Before query execution, it modifies the original SQL query based on provided pagination parameters, adding LIMIT, OFFSET and other pagination conditions, then returns paginated results. Pagination information is provided through the Page class, which encapsulates total record count, total pages, and other information.

Development Steps

  • Import PageHelper coordinates
  • Configure PageHelper plugin in MyBatis core configuration file
  • Test pagination data acquisition

Import pom

<dependency>
    <groupId>com.github.pagehelper</groupId>
    <artifactId>pagehelper</artifactId>
    <version>3.5.1</version>
</dependency>

Plugin Configuration

<plugin interceptor="com.github.pagehelper.PageHelper">
  <property name="dialect" value="mysql"/>
</plugin>

Code Implementation

public class WzkicuPage01 {

    public static void main(String[] args) throws Exception {
        InputStream inputStream = Resources.getResourceAsStream("sqlMapConfig.xml");
        SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder()
                .build(inputStream);
        SqlSession sqlSession = sqlSessionFactory.openSession();
        UserMapper userMapper = sqlSession.getMapper(UserMapper.class);
        PageHelper.startPage(2, 1);
        List<WzkUser> dataList = userMapper.findAll();
        for (WzkUser wzk : dataList) {
            System.out.println(wzk);
        }
    }
}

Execution Results

WzkUser(id=2, username=wzk2, password=icu2, birthday=Mon Nov 11 00:00:00 CST 2024, orderList=null, roleList=null)

Configure PageHelper

Configure PageHelper plugin in Spring configuration file, usually in application.properties or application.yml:

pagehelper.helperDialect=mysql
pagehelper.reasonable=true
pagehelper.supportMethodsArguments=true

PageInfo Class

PageInfo is an important class used by PageHelper to encapsulate pagination query results. It contains pagination-related information:

  • getTotal(): Total record count
  • getPages(): Total page count
  • getPageNum(): Current page number
  • getPageSize(): Page size
  • getList(): Current page data

Notes

  • When using PageHelper, the pagination query must be placed after calling PageHelper.startPage() and before executing the query
  • If using a Mapper interface with @Mapper annotation, PageHelper can automatically work with MyBatis
  • For queries requiring pagination, the returned result must be a List type

Generic Mapper

Brief Introduction

Generic mapper is designed to solve CRUD operations for single tables. Based on MyBatis plugin mechanism, developers don’t need to write SQL or add methods in DAO. They just need to write entity classes to have CRUD methods.

Import Dependency

<dependency>
    <groupId>tk.mybatis</groupId>
    <artifactId>mapper</artifactId>
    <version>3.5.1</version>
</dependency>

Set Primary Key

@Table(name = "wzk_user")
@Data
@Builder
@AllArgsConstructor
@NoArgsConstructor
public class WzkUser implements Serializable {
    private int id;
    private String username;
    private String password;
    private Date birthday;
    private List<WzkOrder> orderList;
    private List<WzkRole> roleList;
}

Modify DAO

public interface UserMapper extends Mapper<WzkUser> {
    // Omit previous content
}

Write Code

public class WzkMapper01 {

    public static void main(String[] args) throws Exception {
        InputStream inputStream = Resources.getResourceAsStream("sqlMapConfig.xml");
        SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder()
                .build(inputStream);
        SqlSession sqlSession = sqlSessionFactory.openSession();
        MapperHelper mapperHelper = new MapperHelper();
        mapperHelper.registerMapper(UserMapper.class);
        mapperHelper.processConfiguration(sqlSession.getConfiguration());
        UserMapper userMapper = sqlSession.getMapper(UserMapper.class);
        List<WzkUser> dataList = userMapper.selectAll();
        for (WzkUser each : dataList) {
            System.out.println(each);
        }
        sqlSession.close();
    }
}

Execution Results

WzkUser(id=0, username=wzk2, password=icu2, birthday=Mon Nov 11 00:00:00 CST 2024, orderList=null, roleList=null)

Example Usage

public class WzkMapper02 {

    public static void main(String[] args) throws Exception {
        InputStream inputStream = Resources.getResourceAsStream("sqlMapConfig.xml");
        SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder()
                .build(inputStream);
        SqlSession sqlSession = sqlSessionFactory.openSession();
        MapperHelper mapperHelper = new MapperHelper();
        mapperHelper.registerMapper(UserMapper.class);
        mapperHelper.processConfiguration(sqlSession.getConfiguration());
        UserMapper userMapper = sqlSession.getMapper(UserMapper.class);

        Example example = new Example(WzkUser.class);
        example.createCriteria().andEqualTo("username", "wzk2");
        List<WzkUser> dataList = userMapper.selectByExample(example);
        for (WzkUser each : dataList) {
            System.out.println(each);
        }
        sqlSession.close();
    }
}

Execution Results

WzkUser(id=0, username=wzk2, password=icu2, birthday=Mon Nov 11 00:00:00 CST 2024, orderList=null, roleList=null)
