MyCAT Installation & Configuration Guide

Download & Installation

  1. Extract installation package:
tar -zxvf Mycat-server-xx-RELEASE-xxxxx-linux.tar.gz
  1. Move to /usr/local:
mv mycat /usr/local/
  1. Set environment variables (optional):
export MYCAT_HOME=/usr/local/mycat
export PATH=$PATH:$MYCAT_HOME/bin

Basic Configuration

Main configuration files for MyCAT are in the conf directory:

  • server.xml: Configure MyCAT service parameters
  • schema.xml: Configure logical database and sharding rules
  • rule.xml: Configure sharding algorithms

Service Management Commands

# Start MyCAT service
./mycat start

# Stop MyCAT service
./mycat stop

# Restart MyCAT service
./mycat restart

# Check service status
./mycat status

Connection Test

mysql -h127.0.0.1 -P8066 -uroot -p123456

Sharding Rules Explained

1. Time-Based Sharding Rules

  • Daily sharding: Store data shards by natural day
  • Natural month sharding: Shard by calendar month
  • Single month hour sharding: Subdivide within a single month by hour

2. Hash-Based Sharding Rules

  • Hash fixed sharding: Calculate standard hash algorithm on key fields then shard
  • Date range hash sharding: First partition by date range, then hash data within partitions
  • Consistent hash sharding: Use consistent hash algorithm to reduce data migration when nodes change

3. Modulo-Based Sharding Rules

  • Modulo sharding: Directly modulo key field values to determine shard
  • Modulo range sharding: First modulo then map to range interval
  • Range modulo sharding: First partition by range, then modulo data within partition

4. Other Sharding Rules

  • Enumeration sharding: Directly map to specific shard based on field enumerated values
  • Range convention sharding: Pre-agree on numerical range for each shard
  • Hot-cold data sharding: Store hot data and cold data separately based on access frequency

Common Sharding Configuration

Modulo Sharding

<tableRule name="mod-long">
  <rule>
    <columns>id</columns>
    <algorithm>mod-long</algorithm>
  </rule>
</tableRule>
<function name="mod-long" class="io.mycat.route.function.PartitionByMod">
  <property name="count">3</property>
</function>

Consistent Sharding

<function name="murmur"
  class="io.mycat.route.function.PartitionByMurmurHash">
  <property name="count">2</property>
  <property name="virtualBucketTimes">160</property>
</function>
