server.xml Overview

server.xml is MyCat’s core configuration file, storing almost all system configuration information needed by MyCat.

Main Configuration Contents

1. System Parameters Configuration

  • MyCat service port (default 8066)
  • Management port (default 9066)
  • Character set configuration
  • Thread pool size
  • Connection timeout

2. User Permission Configuration

  • Define username and password for accessing MyCat
  • Set user permissions (such as read-only, read-write permissions)
  • Configure schemas accessible by users

3. Firewall Configuration

  • Set IP whitelist/blacklist
  • Configure SQL interception rules
  • Define SQL injection protection strategies

4. Performance Tuning Parameters

  • Buffer size settings
  • Connection pool configuration
  • Transaction processing parameters

Global Sequence Number

In the context of implementing database sharding, database auto-increment primary keys cannot guarantee global uniqueness of auto-increment primary keys. MyCat provides multiple global sequence implementation methods:

0 - File Storage Method

Store data in local file system in file form.

1 - Database Storage Method

Use relational database for data storage.

2 - Local Timestamp Method

ID uses 64-bit binary format:

  1. Timestamp section: 42 bits, precise to millisecond level
  2. Machine identifier section: 5 bits, supports up to 32 machines
  3. Business code section: 5 bits, supports 32 business types
  4. Sequence number section: 12 bits, can generate 4096 sequence numbers per millisecond

3 - ZK and Local Configuration Distributed ID Generator

  • ZooKeeper cluster maintains global configuration
  • Local cache worker node information

4 - ZooKeeper Increment Method

Generate incrementing IDs through ZooKeeper’s ordered nodes.

Configuration Example

<!-- User configuration example -->
<user name="user">
    <property name="password">user</property>
    <property name="schemas">wzk_order</property>
</user>
