Spark Streaming Data Sources: File Stream, Socket, RDD Qu...

This is article 86 in the Big Data series, introducing three core Spark Streaming data sources: file stream, Socket stream, and RDD queue stream—principles, use cases, and code implementation.

Full illustrated version: CSDN Original | Juejin

Data Sources Overview

Spark Streaming supports multiple data ingestion methods, categorized by reliability and production suitability:

Data Source	Use Case	Reliability
File Stream	Log rotation, batch file ingestion	High (No Receiver)
Socket Stream	Prototype validation, local testing	Low
RDD Queue Stream	Unit testing, load testing simulation	Test-only
Kafka Direct	Production real-time streaming	Very High (Exactly-Once)

Maven Dependency

<dependency>
  <groupId>org.apache.spark</groupId>
  <artifactId>spark-streaming_2.12</artifactId>
  <version>${spark.version}</version>
</dependency>

File Data Stream

File stream triggers computation by continuously monitoring new files in a specified directory, supporting HDFS, S3, local filesystem, and other Hadoop-compatible storage.

Characteristics:

• No Receiver needed, doesn’t occupy extra CPU cores
• Only processes new files, existing files and modifications don’t trigger
• Doesn’t support nested directories, file formats within directory must be consistent

package icu.wzk

import org.apache.log4j.{Level, Logger}
import org.apache.spark.SparkConf
import org.apache.spark.streaming.{Seconds, StreamingContext}

object FileDStream {
  def main(args: Array[String]): Unit = {
    Logger.getLogger("org").setLevel(Level.ERROR)
    val conf = new SparkConf()
      .setAppName("FileDStream")
      .setMaster("local[*]")

    val ssc = new StreamingContext(conf, Seconds(5))
    // Monitor directory, check for new files every 5 seconds
    val lines = ssc.textFileStream("hdfs://h121.wzk.icu:8020/streaming/input/")
    val words = lines.flatMap(_.split("\\s+"))
    val wordCounts = words.map(x => (x, 1)).reduceByKey(_ + _)

    wordCounts.print()
    ssc.start()
    ssc.awaitTermination()
  }
}

StreamingContext(conf, Seconds(5)) sets micro-batch interval to 5 seconds, textFileStream() monitors directory and automatically processes new files.

Socket Data Stream

Socket stream receives text data from a specified host and port via TCP connection, suitable for quick local logic validation.

Start data sender:

nc -lk 9999

object SocketDStream {
  def main(args: Array[String]): Unit = {
    Logger.getLogger("org").setLevel(Level.ERROR)
    val conf = new SparkConf()
      .setAppName("SocketStream")
      .setMaster("local[*]")
    val ssc = new StreamingContext(conf, Seconds(1))
    val lines = ssc.socketTextStream("0.0.0.0", 9999)
    val words = lines.flatMap(_.split("\\s+"))
    val wordCount = words.map(x => (x.trim, 1)).reduceByKey(_ + _)
    wordCount.print()
    ssc.start()
    ssc.awaitTermination()
  }
}

Batch interval set to 1 second, outputs word frequency statistics every second. Socket stream is simple but has no fault tolerance guarantee—not recommended for production.

RDD Queue Stream

RDD queue stream allows manually placing RDDs into a queue, which Spark Streaming treats as data streams—best for writing test cases and simulating real traffic.

import scala.collection.mutable.Queue

object RDDQueueDStream {
  def main(args: Array[String]): Unit = {
    Logger.getLogger("org").setLevel(Level.WARN)
    val sparkConf = new SparkConf()
      .setAppName("RDDQueueStream")
      .setMaster("local[*]")
    val ssc = new StreamingContext(sparkConf, Seconds(1))

    val rddQueue = new Queue[RDD[Int]]()
    val queueStream = ssc.queueStream(rddQueue)
    val mappedStream = queueStream.map(r => (r % 10, 1))
    val reducedStream = mappedStream.reduceByKey(_ + _)
    reducedStream.print()

    ssc.start()

    // Produce one batch every 2 seconds, total 5 batches
    for (i <- 1 to 5) {
      rddQueue.synchronized {
        val range = (1 to 100).map(_ * i)
        rddQueue += ssc.sparkContext.makeRDD(range, 2)
      }
      Thread.sleep(2000)
    }

    ssc.stop()
  }
}

Key Points:

• rddQueue.synchronized ensures thread safety
• Take modulo 10 of integers and count groupings to verify aggregation logic
• Full control over data content, quantity, and production rate—flexible testing scenarios

Notes

When running with local[*], if CPU core count is 1, the Receiver thread will consume all resources causing data processing failure. It’s recommended to explicitly specify local[2] or higher, ensuring at least one core for data processing.

For production, prefer Kafka Direct mode—native Exactly-Once semantics support, throughput and reliability far superior to Socket.
