SparkSQL Statements: DataFrame Operations, SQL Queries & ...

This is article 83 in the Big Data series, introducing SparkSQL statement writing and Hive integration configuration practices.

SparkSQL Overview

SparkSQL is Apache Spark’s core module for processing structured and semi-structured data, providing two query methods:

• DataFrame API: Imperative operations with type safety, seamless integration with Scala/Java
• SQL Strings: Declarative queries, over 90% compatible with HiveQL syntax

Both are processed through the Catalyst optimizer with consistent performance.

---

DataFrame API Operations

Reading Data

// Read JSON file
val df = spark.read.json("people.json")
df.show()
df.printSchema()

// Read CSV file (with header)
val df2 = spark.read
  .option("header", "true")
  .option("inferSchema", "true")
  .csv("employees.csv")

Register Temporary Views

DataFrames can be registered as temporary views for SQL queries:

df.createOrReplaceTempView("people")
spark.sql("SELECT name, age FROM people WHERE age > 20").show()

Supported Data Source Formats

Format	Characteristics
Parquet	Columnar storage, high compression, nested structures, Spark default
JSON	Lightweight format, nested support, Web-friendly
CSV	Common flat format, simple but no nested support
Avro	Row-based serialization, schema evolution
ORC	High compression, I/O optimization, Hive-compatible
Hive Table	Seamless Hive metadata integration, HiveQL syntax support

---

SQL Query Syntax Practice

Basic Queries

spark.sql("""
  SELECT name, age, salary
  FROM employees
  WHERE age > 25
  ORDER BY salary DESC
  LIMIT 10
""").show()

Aggregation and Grouping

spark.sql("""
  SELECT department,
         COUNT(*) AS headcount,
         AVG(salary) AS avg_sal,
         MAX(salary) AS max_sal
  FROM employees
  GROUP BY department
  HAVING AVG(salary) > 5000
""").show()

Window Functions

spark.sql("""
  SELECT name, department, salary,
         RANK() OVER (PARTITION BY department ORDER BY salary DESC) AS rk
  FROM employees
""").show()

---

Advanced Feature: lateral view explode

lateral view explode is a powerful tool in SparkSQL for handling array/Map type columns, similar to row expansion in SQL.

Scenario Example

Data as follows, each row’s tags field is a comma-separated tag list:

1 1,2,3
2 2,3
3 1,2

Implementation:

case class Info(id: String, tags: String)

val arr = Array("1 1,2,3", "2 2,3", "3 1,2")
val rdd = sc.makeRDD(arr).map { line =>
  val fields = line.split("\\s+")
  Info(fields(0), fields(1))
}

val df = rdd.toDF()
df.createOrReplaceTempView("t1")

spark.sql(
  """SELECT id, tag
    |FROM t1
    |LATERAL VIEW explode(split(tags, ',')) t2 AS tag
  """.stripMargin
).show()

Output:

+---+---+
| id|tag|
+---+---+
|  1|  1|
|  1|  2|
|  1|  3|
|  2|  2|
|  2|  3|
|  3|  1|
|  3|  2|
+---+---+

---

Hive Integration

Dependency Configuration

<dependency>
  <groupId>org.apache.spark</groupId>
  <artifactId>spark-hive_2.12</artifactId>
  <version>${spark.version}</version>
</dependency>

Enable Hive Support

val spark = SparkSession.builder()
  .appName("SparkHiveDemo")
  .master("local[*]")
  .config("spark.sql.warehouse.dir", "/user/hive/warehouse")
  .enableHiveSupport()   // Key: Enable Hive metadata support
  .getOrCreate()

Read/Write Hive Tables

// Read Hive table
spark.sql("SELECT * FROM ods.user_behavior LIMIT 100").show()

// Write to Hive table (append)
resultDf.write.mode("append").saveAsTable("dwd.user_behavior_clean")

// Partitioned write
resultDf.write
  .partitionBy("dt")
  .mode("overwrite")
  .saveAsTable("dwd.user_behavior_partitioned")

SparkSQL vs HiveQL Performance Comparison

SparkSQL reduces latency from minute-level (HiveQL) to millisecond-second level through in-memory computing:

Metric	SparkSQL	HiveQL (MapReduce)
In-memory computing	Supported	Not supported
Latency	Millisecond~Second	Minute-level
Syntax compatibility	90%+ HiveQL compatible	Native HiveQL
UDF support	Supports Hive UDF	Supported

---

Summary

SparkSQL’s three usage methods are equivalent at the execution level—the choice depends on development scenario:

• DataFrame API: Suitable for type-safe data processing in Scala/Java programs
• SQL Strings: Suitable for data analysts or scenarios needing quick logic verification
• Hive Integration: Suitable for enterprises with existing Hive data warehouses using Spark to accelerate queries

For most enterprise data warehouse scenarios, using enableHiveSupport() mode is recommended—it reuses existing Hive metadata and provides orders of magnitude performance improvement through SparkSQL.
