Spring Boot Integration with Kafka

This is article 56 in the Big Data series, introducing how to integrate Apache Kafka in Spring Boot for sync/async message sending and annotation-driven consumption.

Kafka Core Concepts Review

Before integrating with Spring Boot, review key roles:

• Producer: Message publisher, writes messages to specified Topic, supports batch sending, ACK confirmation, and custom partitioning strategy.
• Consumer: Pulls messages from Broker, can join Consumer Group to collectively consume a Topic.
• Broker: Single node in Kafka cluster, responsible for receiving, persisting messages, and maintaining replicas.
• Topic / Partition: Topic is message classification; Partition is ordered, immutable shard of Topic, distributed across Brokers for parallel consumption.
• Consumer Group: Within same Group, each Partition only assigned to one Consumer, naturally implements load balancing.

Project Dependencies

Using Spring Boot 2.2.x + Java 8, add to pom.xml:

<parent>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-parent</artifactId>
    <version>2.2.2.RELEASE</version>
</parent>

<dependencies>
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-web</artifactId>
    </dependency>
    <dependency>
        <groupId>org.springframework.kafka</groupId>
        <artifactId>spring-kafka</artifactId>
    </dependency>
</dependencies>

application.yml Configuration

spring:
  kafka:
    bootstrap-servers: localhost:9092
    producer:
      key-serializer: org.apache.kafka.common.serialization.StringSerializer
      value-serializer: org.apache.kafka.common.serialization.StringSerializer
    consumer:
      group-id: my-group
      auto-offset-reset: earliest
      key-deserializer: org.apache.kafka.common.serialization.StringDeserializer
      value-deserializer: org.apache.kafka.common.serialization.StringDeserializer

auto-offset-reset: earliest means when Consumer has no committed Offset, start consuming from earliest message.

Producer Implementation

Spring-Kafka provides KafkaTemplate wrapping underlying sending logic:

@RestController
public class ProducerController {

    @Autowired
    private KafkaTemplate<String, String> kafkaTemplate;

    // Sync send: block waiting for Broker confirmation
    @GetMapping("/sendSync/{message}")
    public String sendSync(@PathVariable String message) throws Exception {
        ProducerRecord<String, String> record =
            new ProducerRecord<>("wzk_topic_test", message);
        RecordMetadata metadata = kafkaTemplate.send(record).get(); // block
        return "partition=" + metadata.partition() + ", offset=" + metadata.offset();
    }

    // Async send: handle result via callback
    @GetMapping("/sendAsync/{message}")
    public String sendAsync(@PathVariable String message) {
        ProducerRecord<String, String> record =
            new ProducerRecord<>("wzk_topic_test", message);
        kafkaTemplate.send(record).addCallback(
            result -> System.out.println("Send success: " + result.getRecordMetadata().offset()),
            ex   -> System.err.println("Send failed: " + ex.getMessage())
        );
        return "async sent";
    }
}

Sync vs Async selection: Sync is simple and reliable but low throughput; Async suitable for high concurrency scenarios, handle retry in callback.

Consumer Implementation

Use @KafkaListener annotation to declare consumer, framework auto-manages offset commit:

@Component
public class KafkaConsumer {

    @KafkaListener(topics = {"wzk_topic_test"}, groupId = "my-group")
    public void consume(ConsumerRecord<String, String> record) {
        System.out.printf("topic=%s, partition=%d, offset=%d, key=%s, value=%s%n",
            record.topic(), record.partition(), record.offset(),
            record.key(), record.value());
    }
}

ConsumerRecord contains complete message metadata (topic, partition, offset, key, value), convenient for troubleshooting message loss or duplicate consumption.

Spring-Kafka Core Components Summary

Component	Description
KafkaTemplate	Producer send wrapper, supports sync/async modes
@KafkaListener	Declarative consumer, auto completes subscription, deserialization, offset commit
ConsumerRecord	Complete message object received by consumer
ProducerRecord	Message object constructed by producer, can specify topic, partition, key

Verification

After starting the application, access /sendSync/hello, console output similar to:

Send success: partition=0, offset=42
topic=wzk_topic_test, partition=0, offset=42, key=null, value=hello

Indicates message flows successfully from production to consumption. Next article will dive into Producer internal sending flow and core parameter tuning.
