This is article 34 in the Big Data series. Records complete steps of HBase single node installation and configuration on top of existing Hadoop + ZooKeeper cluster.

Complete illustrated version: CSDN Original | Juejin

Prerequisites

This article configures based on following ready environment:

  • Three 2C4G cloud servers: h121, h122, h123
  • Hadoop 2.9.2 cluster running normally (HDFS, YARN)
  • ZooKeeper 3.x three-node cluster running
  • SSH passwordless between nodes configured
  • JDK 8 installed

Download and Extract

Execute on h121 node:

# Download HBase 1.3.1
wget https://archive.apache.org/dist/hbase/1.3.1/hbase-1.3.1-bin.tar.gz

# Extract to unified installation directory
tar -zxvf hbase-1.3.1-bin.tar.gz -C /opt/servers

Associate Hadoop Configuration

HBase needs to be aware of HDFS configuration, import Hadoop configuration files via symlink or copy:

# Symlink core-site.xml (recommended, keep in sync)
ln -s /opt/servers/hadoop-2.9.2/etc/hadoop/core-site.xml \
    /opt/servers/hbase-1.3.1/conf/core-site.xml

# Copy hdfs-site.xml
cp /opt/servers/hadoop-2.9.2/etc/hadoop/hdfs-site.xml \
    /opt/servers/hbase-1.3.1/conf/hdfs-site.xml

Core Configuration Files

hbase-env.sh

# Specify JDK path
export JAVA_HOME=/usr/lib/jvm/java-8-openjdk-amd64

# Disable HBase built-in ZooKeeper, use external standalone ZooKeeper cluster
export HBASE_MANAGES_ZK=FALSE

HBASE_MANAGES_ZK=FALSE is key configuration: production environment should always use independent ZooKeeper cluster, not HBase’s built-in ZooKeeper, for unified management and avoiding resource competition.

hbase-site.xml

<configuration>
  <!-- HBase data storage path on HDFS -->
  <property>
    <name>hbase.rootdir</name>
    <value>hdfs://h121.wzk.icu:9000/hbase</value>
  </property>

  <!-- Enable distributed mode (different from local pseudo-distributed) -->
  <property>
    <name>hbase.cluster.distributed</name>
    <value>true</value>
  </property>
</configuration>
