Overview

This article introduces completing parsing, cleaning, and detail modeling from ODS to DWD for offline data warehouse based on advertising events in tracking logs. The core pipeline can be implemented, but there are some risk points in current script and field design.

Requirements Analysis

Event Log Data Sample

{
  "wzk_event": [{
    "name": "goods_detail_loading",
    "json": {
      "entry": "3",
      "goodsid": "0",
      "loading_time": "80",
      "action": "4",
      "staytime": "68",
      "showtype": "4"
    },
    "time": 1596225273755
  }, {
    "name": "loading",
    "json": {
      "loading_time": "18",
      "action": "1",
      "loading_type": "2",
      "type": "3"
    },
    "time": 1596231657803
  }, ...

Collected Event Types

  • Goods detail page loading: goods_detail_loading
  • Goods list: loading
  • Message notification: notification
  • Product comment: comment
  • Favorites: favorites
  • Like/Praise: praise
  • Advertisement: ad

Advertising Field Description

  • action: User behavior (0 impression, 1 click after impression, 2 purchase)
  • duration: Stay duration
  • shop_id: Merchant id
  • event_type: “ad”
  • ad_type: 1 JPG, 2 PNG, 3 GIF, 4 SWF
  • show_style: 0 static image, 1 dynamic image
  • product_id: Product id
  • place: Ad placement (1 homepage, 2 left, 3 right, 4 list page)
  • sort: Sort position

Requirements Metrics

Click Count Statistics (Hourly Statistics)

  • Impression count, distinct user ID count, distinct user count
  • Click count, distinct user ID count, distinct user count
  • Purchase count, distinct user ID count, distinct user count

Conversion Rate - Funnel Analysis

  • Click-through rate = Click count / Impression count
  • Purchase rate = Click count / Click count

Campaign Impression Effect Evaluation

  • Behavior (impression, click, purchase), time period, ad placement, product, count corresponding times
  • Time period, ad placement, product, top N with most impression counts

ODS Layer

Create External Table

use ods;
drop table if exists ods.ods_log_event;
CREATE EXTERNAL TABLE ods.ods_log_event(
  `str` string
) PARTITIONED BY (`dt` string)
STORED AS TEXTFILE
LOCATION '/user/data/logs/event';

Partition Loading Script

vim /opt/wzk/hive/ods_load_event_log.sh

#!/bin/bash
source /etc/profile
if [ -n "$1" ]
then
  do_date=$1
else
  do_date=`date -d "-1 day" +%F`
fi
sql="
alter table ods.ods_log_event add partition (dt='$do_date');
"
hive -e "$sql"

DWD Layer

Create Event Detail Table

use dwd;
-- All event details
drop table if exists dwd.dwd_event_log;
CREATE EXTERNAL TABLE dwd.dwd_event_log(
  `device_id` string,
  `uid` string,
  `app_v` string,
  `os_type` string,
  `event_type` string,
  `language` string,
  `channel` string,
  `area` string,
  `brand` string,
  `name` string,
  `event_json` string,
  `report_time` string)
PARTITIONED BY (`dt` string)
stored as parquet;

Create Advertising Detail Table

use dwd;
-- Advertising click detail
drop table if exists dwd.dwd_ad;
CREATE TABLE dwd.dwd_ad(
  `device_id` string,
  `uid` string,
  `app_v` string,
  `os_type` string,
  `event_type` string,
  `language` string,
  `channel` string,
  `area` string,
  `brand` string,
  `report_time` string,
  `duration` int,
  `ad_action` int,
  `shop_id` int,
  `ad_type` int,
  `show_style` smallint,
  `product_id` int,
  `place` string,
  `sort` int,
  `hour` string
)
PARTITIONED BY (`dt` string)
stored as parquet;

UDF Development

UDF Purpose

  • Implement complex business logic encapsulation
  • Improve code reusability
  • Extend SQL functionality
  • Optimize query performance

JSON Array Parsing UDF

public class ParseJsonArray extends UDF {
    public ArrayList<String> evaluate(String jsonStr) {
        if (Strings.isNullOrEmpty(jsonStr)) {
            return null;
        }
        try{
            // Get jsonArray
            JSONArray jsonArray = JSON.parseArray(jsonStr);
            ArrayList<String> lst = new ArrayList<>();
            for(Object o: jsonArray) {
                lst.add(o.toString());
            }
            return lst;
        }catch (JSONException e){
            return null;
        }
    }
}

Data Loading Scripts

Event Log Loading Script

vim /opt/wzk/hive/dwd_load_event_log.sh

USE dwd;
add jar /opt/wzk/hive-parse-json-array-1.0-SNAPSHOT-jar-with-dependencies.jar;
CREATE temporary function wzk_json_array AS 'icu.wzk.ParseJsonArray';

WITH tmp_start AS (
  SELECT SPLIT(str, ' ')[7] AS line
  FROM ods.ods_log_event
  WHERE dt='$do_date'
)

-- Insert data into target table dwd_event_log
INSERT OVERWRITE TABLE dwd.dwd_event_log
PARTITION (dt='$do_date')
SELECT
  device_id,
  uid,
  app_v,
  os_type,
  event_type,
  language,
  channel,
  area,
  brand,
  get_json_object(k, '$.name') AS name,
  get_json_object(k, '$.json') AS json,
  get_json_object(k, '$.time') AS time
FROM (
  SELECT
    get_json_object(line, '$.attr.device_id') AS device_id,
    get_json_object(line, '$.attr.uid') AS uid,
    get_json_object(line, '$.attr.app_v') AS app_v,
    get_json_object(line, '$.attr.os_type') AS os_type,
    get_json_object(line, '$.attr.event_type') AS event_type,
    get_json_object(line, '$.attr.language') AS language,
    get_json_object(line, '$.attr.channel') AS channel,
    get_json_object(line, '$.attr.area') AS area,
    get_json_object(line, '$.attr.brand') AS brand,
    get_json_object(line, '$.wzk_event') AS wzk_event,
    line
  FROM tmp_start
) A
LATERAL VIEW EXPLODE(wzk_json_array(line, 'wzk_event')) B AS k;

hive -e "$sql"

Advertising Log Loading Script

vim /opt/wzk/hive/dwd_load_ad_log.sh

#!/bin/bash
source /etc/profile
if [ -n "$1" ]; then
  do_date=$1
else
  do_date=$(date -d "-1 day" +%F)
fi

sql="
INSERT OVERWRITE TABLE dwd.dwd_ad
PARTITION (dt='$do_date')
SELECT
  device_id,
  uid,
  app_v,
  os_type,
  event_type,
  language,
  channel,
  area,
  brand,
  report_time,
  get_json_object(event_json, '$.duration') AS duration,
  get_json_object(event_json, '$.ad_action') AS ad_action,
  get_json_object(event_json, '$.shop_id') AS shop_id,
  get_json_object(event_json, '$.ad_type') AS ad_type,
  get_json_object(event_json, '$.show_style') AS show_style,
  get_json_object(event_json, '$.product_id') AS product_id,
  get_json_object(event_json, '$.place') AS place,
  get_json_object(event_json, '$.sort') AS sort,
  from_unixtime(ceil(report_time/1000), 'HH') AS report_hour
FROM dwd.dwd_event_log
WHERE dt='$do_date' AND name='ad';
"

hive -e "$sql"

Error Troubleshooting

SymptomRoot CauseFix
UDF call reports parameter mismatchJava UDF evaluate(String) only accepts 1 parameter, but SQL written as wzk_json_array(line, ‘wzk_event’)Check UDF class signature and call parameter count
Many advertising fields parsed as nullRequired field is action, but script gets $.ad_actionChange $.ad_action to $.action according to original tracking JSON
place, action field type confusionTable structure and tracking field type design inconsistentUnify numeric field types
Hour field cannot be correctly generatedreport_time is string type directly participates in calculationExplicitly cast to bigint: from_unixtime(cast(report_time as bigint)/1000, ‘HH’)
Event split result abnormalSPLIT(str, ’ ’)[7] depends on fixed space positionChange to more stable regex extraction or directly write JSON original to lake
Field meaning confusionSELECT alias doesn’t match target table field nameExplicitly use alias consistent with table structure

Data Flow Pipeline

Log => Flume => ODS Layer => Cleaning, Transformation => DWD Layer (Event Detail) => Advertising Event Filtering => Advertising Wide Table

Through this solution, hourly statistics, funnel conversion rate analysis, and ad placement effect evaluation for advertising impressions, clicks, and purchases can be implemented.
