Offline Data Warehouse Practice: Flume+HDFS+Hive Building...

Overview

This article demonstrates a complete offline data warehouse pipeline from log collection to member metric analysis. Flume Taildir monitors local log directories, writes data to HDFS partition directories, then Hive external tables load to ODS, further clean to DWD, ultimately supporting active members, new members, member retention metrics calculation.

Data Flow

Data Collection => ODS => DWD => DWS => ADS => MySQL
Active Members, New Members, Member Retention

Script Execution Order

# Load ODS / DWD layer collection
ods_load_startlog.sh
dwd_load_startlog.sh
# Active Members
dws_load_member_start.sh
ads_load_member_active.sh
# New Members
dws_load_member_add_day.sh
ads_load_member_add.sh
# Member Retention
dws_load_member_retention_day.sh
ads_load_member_retention.sh

Flume Configuration

Monitor log directory: /opt/wzk/logs/start/.*log

a1.sources = r1
a1.sinks = k1
a1.channels = c1

# taildir source
a1.sources.r1.type = TAILDIR
a1.sources.r1.positionFile = /opt/wzk/conf/startlog_position.json
a1.sources.r1.filegroups = f1 f2
a1.sources.r1.filegroups.f1 = /opt/wzk/logs/start/.*log
a1.sources.r1.headers.f1.logtype = start
a1.sources.r1.filegroups.f2 = /opt/wzk/logs/event/.*log
a1.sources.r1.headers.f2.logtype = event

# custom interceptor
a1.sources.r1.interceptors = i1
a1.sources.r1.interceptors.i1.type = icu.wzk.LogTypeInterceptor$Builder

# memorychannel
a1.channels.c1.type = memory
a1.channels.c1.capacity = 100000
a1.channels.c1.transactionCapacity = 2000

# hdfs sink
a1.sinks.k1.type = hdfs
a1.sinks.k1.hdfs.path = /user/data/logs/%{logtype}/dt=%{logtime}/
a1.sinks.k1.hdfs.filePrefix = startlog.
a1.sinks.k1.hdfs.fileType = DataStream
a1.sinks.k1.hdfs.rollSize = 33554432
a1.sinks.k1.hdfs.batchSize = 1000

Start command:

flume-ng agent --conf-file /opt/wzk/flume-conf/flume-log2hdfs2.conf -name a1 -Dflume.roog.logger=INFO,console

HDFS Data Cleanup

hadoop fs -rm -r /user/data/logs/start/
hadoop fs -rm -r /user/data/logs/event/

hadoop fs -mkdir /user/data/logs/start
hadoop fs -mkdir /user/data/logs/event

ODS Layer

Definition

ODS (Operational Data Store) is the operational data storage layer, used to store raw data extracted from business systems, serving as the “data input” of the data warehouse.

Functions

Data Complete Storage: Maintains data originality for problem tracing
Decoupling: Implements isolation between business systems and data warehouse
Real-time Support: If data needs real-time analysis, ODS can support near-real-time data synchronization

Load ODS

sh ods_load_startlog.sh 2020-07-21

Hive query:

use ods;
select * from ods_start_log limit 3;

DWD Layer

Definition

DWD (Data Warehouse Detail) is the detail data layer, storing cleaned and lightly processed wide table data.

Functions

Data Refinement: Cleaned and standardized data for subsequent subject modeling
Performance Optimization: Reduces data cleaning and transformation overhead for subsequent queries
Dimension Wide Table: Wide table joins multiple tables for business analysis

Data Processing

Data Cleaning: Remove dirty data, handle null values, unify formats
Data Integration: Join multiple tables according to business logic, add computed fields
Deduplication and Normalization: Ensure data uniqueness

Load DWD

sh dwd_load_startlog.sh 2020-07-21

Hive query:

use dwd;
select * from dwd.dwd_start_log limit 3;

Error Troubleshooting

Symptom	Root Cause	Fix
No expected log output after Flume starts	Start parameter spelling error	Check and change `-Dflume.roog.logger` to standard logger parameter
HDFS cleanup causes subsequent collection directory exception	Inconsistent spelling between enent and event	Compare delete command with create command, unify to event
Flume cannot monitor files	Monitor directory inconsistent with copy directory	Check filegroups regex and cp target directory
HDFS has directory but Hive cannot find data	Partition directory date field depends on interceptor	Check custom interceptor LogTypeInterceptor output header
ODS queryable but DWD has no data	DWD script date parameter doesn’t match ODS actual partition	Verify script parameters and ODS partition unify business date口径
No new consumption after log file copied	Taildir positionFile recorded old offset	Check positionFile cleanup or reset before test
HDFS file rolling abnormal	rollCount/rollInterval/idleTimeout all set to 0	Check sink rolling parameter settings for reasonable thresholds
Dates in article confusing	Sample log time spans 2020/2021/2024	Verify date fragments in main text unify demo date
