Big Data 190 - Filebeat → Kafka → Logstash → Elasticsearch Practice

1. Overall Architecture

Filebeat → Kafka → Logstash → Elasticsearch → Kibana

2. Filebeat Configuration

2.1 Installation

• 7.3.0 or 7.17.0

2.2 filebeat.yml

filebeat.inputs:
  - type: log
    paths:
      - /var/log/nginx/access.log
    json.keys_under_root: true
    json.overwrite_keys: true

output.kafka:
  hosts: ["h121:9092", "h122:9092", "h123:9092"]
  topic: "nginx-log"
  partition.hash:
    hash: []

3. Logstash Configuration

3.1 Consume from Kafka

input {
  kafka {
    bootstrap_servers => "h121:9092,h122:9092,h123:9092"
    topics => ["nginx-log"]
    group_id => "logstash-group"
  }
}

3.2 Parse JSON

filter {
  if [type] == "app" {
    json {
      source => "message"
      target => "parsed"
    }
  }
}

3.3 GeoIP Enhancement

filter {
  geoip {
    source => "remote_addr"
    database => "GeoLite2-City.mmdb"
  }
}

3.4 Output to ES

output {
  elasticsearch {
    hosts => ["h121:9200", "h122:9200", "h123:9200"]
    index => "logstash-%{type}-%{+YYYY.MM.dd}"
  }
}

4. Complete Configuration Example

4.1 filebeat.yml (Simplified)

filebeat.inputs:
  - type: log
    paths:
      - /var/log/nginx/access.log

output.kafka:
  hosts: ["h121:9092"]
  topic: "nginx-log"

4.2 logstash_kafka_es.conf

input {
  kafka {
    bootstrap_servers => "h121:9092"
    topics => ["nginx-log"]
  }
}

filter {
  geoip {
    source => "remote_addr"
  }
}

output {
  elasticsearch {
    hosts => ["h121:9200"]
    index => "logstash-%{+YYYY.MM.dd}"
  }
}

5. Error Quick Reference

Issue	Possible Cause	Solution
Filebeat fails to start	Config file error	Check yml syntax
Kafka can’t consume data	Topic doesn’t exist	Create Topic
GeoIP not effective	IP format incorrect	Check remote_addr field
Index has no data	ES write failed	Check ES status

6. Summary

• Filebeat collects logs and sends to Kafka
• Logstash consumes from Kafka
• Use geoip plugin to add geographic information
• Write data to ES for Kibana display
