Big Data 181 - Elasticsearch Segment Merge & Disk Directory Breakdown

1. Background: Why Need Segment Merge

Elasticsearch writes are “append-type”, when indexing documents doesn’t directly update existing documents:

1. New document written to memory Buffer
2. When refresh, Buffer content written to new Segment
3. Segments are Immutable

Refresh frequency default is once per second, meaning new Segment created every second. More segments, more problems:

• File handle occupation (each segment needs to open multiple files)
• Memory overhead (each segment has independent data structure)
• CPU consumption (query needs to merge results from multiple segments)
• Disk space (deleted documents not released, only marked)

Segment Merge is merging small segments into large ones in background, cleaning deleted documents.

2. Merge Policy Config

2.1 Core Parameters

Parameter	Default	Meaning
index.merge.policy.floor_segment	2MB	Segments smaller than this are ignored, don’t participate in merge
index.merge.policy.max_merge_at_once	10	Maximum segments participating in each merge
index.merge.policy.max_merged_segment	5GB	Maximum segment size after merge
index.merge.policy.segments_per_tier	10	Minimum segments per tier (works with max_merge_at_once)

2.2 Config Example

{
  "settings": {
    "index.merge.policy.max_merge_at_once": 20,
    "index.merge.policy.max_merged_segment": "10gb"
  }
}

3. Force Merge

Force merge used for read-only/archive scenarios, manually merge segments into fewer:

POST /my-index/_forcemerge?max_num_segments=1

Note:

• Will generate large I/O, recommended to execute during business low peak
• Cannot be rolled back after completion
• Read-only indexes should use this operation for archiving

4. ES Data Directory Structure

nodes/
  └── 0/
      └── indices/
          └── {index-uuid}/
              └── 0/
                  ├── _state/
                  │   └── state-1.st
                  ├── index/
                  │   ├── _0.cfe
                  │   ├── _0.cfs
                  │   └── _0.si
                  └── translog/
                      └── translog.ckp

4.1 Core File Types

File Suffix	Meaning
.cfe	Compound file entry
.cfs	Compound file data
.si	Segment info
.doc	DocValues
.dim	BKD tree (geo coordinates)
.pos	Position info
.tip	Term Index

5. Summary

• Segment merge executed automatically by background threads
• Reasonably config Merge Policy can balance write performance and query efficiency
• Force Merge only applicable to read-only indexes
• Understanding directory structure helps troubleshooting issues
