Flume Hello World: NetCat Source + Memory Channel + Logge...

This is article 18 in the Big Data series. Demonstrates complete Source→Channel→Sink data flow pipeline through simplest Flume case.

Complete illustrated version: CSDN Original | Juejin

Case Goal

Build simplest Flume Agent using three components:

Source: netcat source, monitors TCP port, receives text via telnet
Channel: memory channel, caches Events in JVM memory
Sink: logger sink, prints Event content to console

This is the standard Hello World scenario to verify Flume installation.

Component Description

Component	Type	Features
netcat source	`netcat`	Monitors TCP port, each line input becomes an Event
memory channel	`memory`	High performance, data may be lost on process crash
logger sink	`logger`	Outputs to console log, for debugging only

Configuration File

Create directory and config file /opt/wzk/flume_test/flume-netcat-logger.conf:

mkdir -p /opt/wzk/flume_test

Configuration file content:

# Declare three component names for Agent
a1.sources = r1
a1.channels = c1
a1.sinks = k1

# Source config: monitor TCP port 8888
a1.sources.r1.type = netcat
a1.sources.r1.bind = h122.wzk.icu
a1.sources.r1.port = 8888

# Channel config: memory buffer
a1.channels.c1.type = memory
a1.channels.c1.capacity = 10000
a1.channels.c1.transactionCapacity = 100

# Sink config: output to console log
a1.sinks.k1.type = logger

# Binding: Source connects to Channel, Sink connects to Channel
a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1

Key parameter explanations:

capacity: Maximum Events Channel can buffer (10000)
transactionCapacity: Maximum Events per transaction (100)
bind: Hostname or IP for netcat to monitor

Start Flume Agent

Confirm port 8888 is not in use:

lsof -i:8888

Start Agent, specify Agent name and config file:

$FLUME_HOME/bin/flume-ng agent \
  --name a1 \
  --conf-file /opt/wzk/flume_test/flume-netcat-logger.conf \
  -Dflume.root.logger=INFO,console

Parameter explanations:

--name a1: Matches Agent name in config file
--conf-file: Config file path
-Dflume.root.logger=INFO,console: Set log level to INFO and output to console

Send Test Data

Install telnet client (if not installed):

sudo apt install telnet

In another terminal, connect to Flume listening port:

telnet h122.wzk.icu 8888

After successful connection, enter any text and press Enter, for example:

hello flume
big data test

Observe Output

Go back to terminal where Flume started, can see log output similar to:

INFO sink.LoggerSink: Event: { headers:{} body: 68 65 6C 6C 6F 20 66 6C 75 6D 65  hello flume }
INFO sink.LoggerSink: Event: { headers:{} body: 62 69 67 20 64 61 74 61 20 74 65  big data te }

Event body shows both hexadecimal and readable text, indicating data successfully passed through Source → Channel → Sink complete pipeline.

Summary

This case verifies Flume’s basic working principle: Source receives data and packages as Event, Channel buffers, Sink consumes Event and writes out. Subsequent cases will replace Sink with HDFS Sink to implement real log collection to disk.
