Apache Kylin 1.6 Streaming Cubing Practice: Kafka to Minu...

TL;DR

Scenario: Real-time data stream (Kafka) connected to Kylin, achieving minute-level OLAP analysis
Conclusion: Streaming Cubing supports real-time aggregation queries with 3-5 minute latency
Output: Kafka config, message format, build command, scheduled execution

Streaming Cubing Overview

What is Streaming Cubing

Apache Kylin V1.6 released Streaming Cubing feature for real-time data update requirements, integrates Hadoop ecosystem processing capability to consume Kafka message queue data in real-time, achieves minute-level (typically 3-5 minutes) updated Cube.

Core Features

Consume Kafka message queue
Minute-level data updates
Same query syntax as offline Cube
Supports Lambda architecture (realtime + batch)

Implementation Steps

1. Create Project

Create project in Kylin Web UI.

2. Define Data Source (Kafka)

Data Source → Add Streaming Table

3. Define Model

Model → Streaming Model

4. Define Cube

Cube → Streaming Cube

5. Build Cube

Build → Streaming Build

6. Job Scheduling

Use crontab to schedule incremental build periodically.

Message Body JSON Structure

Requirements

{
  "dimensions": {
    "region": "APAC",
    "product_line": "smartphone"
  },
  "metrics": {
    "order_count": 42,
    "revenue": 12500.00
  },
  "timestamp": "2023-05-15T09:15:30Z"
}

Three-part JSON

dimensions: Dimension fields
metrics: Measure fields
timestamp: Timestamp

Time Partition Column

Place time partition column (like minute_start) before RowKeys.

Build Commands

REST API Build

curl -X PUT --user ADMIN:KYLIN \
  -H "Content-Type:application/json;charset=utf-8" \
  -d '{
    "sourceOffsetStart": 0,
    "sourceOffsetEnd": 9223372036854775807,
    "buildType": "BUILD"
  }' \
  http://h122.wzk.icu:7070/kylin/api/cubes/streaming_cube1/build2

Parameter Description

sourceOffsetStart: Kafka start offset
sourceOffsetEnd: Kafka end offset
buildType: BUILD (incremental)

Auto Build (crontab)

Every 20 minutes incremental build

*/20 * * * * curl -X PUT --user ADMIN:KYLIN \
  -H "Content-Type:application/json;charset=utf-8" \
  -d '{
    "sourceOffsetStart": 0,
    "sourceOffsetEnd": 9223372036854775807,
    "buildType": "BUILD"
  }' \
  http://h122.wzk.icu:7070/kylin/api/cubes/streaming_cube1/build2

Micro-batch Build & Refresh Merge Window

Window Type	Time Interval
0.5h	30 minutes
4h	4 hours
1d	1 day
7d	7 days

Typical Application Scenarios

E-commerce Transaction Analysis

Real-time sales statistics
Order volume monitoring
Regional sales ranking

User Behavior Analysis

Real-time UV/PV
Click stream analysis
User profile real-time updates

IoT Device Monitoring

Sensor data aggregation
Anomaly alerts
Device status real-time statistics

Parser Config

TimedJsonStreamParser

Use TimedJsonStreamParser to parse three-part JSON:

Automatically extract dimensions
Automatically extract metrics
Automatically extract timestamp

Time Partition

minute_start: Minute-level partition
hour_start: Hour-level partition
day_start: Day-level partition

Error Quick Reference

Symptom	Root Cause Location	Fix
Kafka consumption lag	Network/partitions/consumer capacity	Check consumer concurrency, increase partition count
Data loss	Offset commit strategy	Ensure offsets.commit.interval.ms config
Build fails	JSON format error	Validate message body format
Query latency high	Too many Segments	Configure auto merge strategy
