Apache Kylin Cube Practice: Complete Guide for Modeling, ...

TL;DR

Scenario: E-commerce sales data multi-dimensional analysis, Cube modeling and pre-computation by date/region/product/channel
Conclusion: Star modeling + Aggregation Group pruning can significantly reduce Cuboid count, queries achieve second-level response
Output: Complete modeling flow, dimension design principles, Cuboid optimization strategies, error quick reference table

Version Matrix

Module	Technical Points	Engineering Suggestions
Star Modeling	Fact table + dimension table, single table ≤300MB	Dimension table primary key unique, avoid Hive views
Dimension Design	Date/region/product/channel	High-frequency dimensions first, hierarchy dimensions handle separately
Measure Design	SUM/COUNT/AVG/MAX/MIN	Count Distinct needs cardinality evaluation
Aggregation Group	Dimension grouping, combination control	Split into multiple groups when dimension >15
Mandatory Dimension	Must appear in WHERE/GROUP BY	Reduce invalid Cuboids
Hierarchy Dimension	Country→Province→City	Only pre-compute finest granularity
Joint Dimension	Low cardinality/often queried together	Either appear together or both not appear
Build Engine	Hive + Spark + HBase	Spark build replace MapReduce
Query Acceleration	Cuboid matching	Ensure query hits pre-computed results

Modeling Flow

1. Data Preparation

-- Fact table: E-commerce sales records
CREATE TABLE fact_sales (
  order_id STRING,
  dt DATE COMMENT 'partition field',
  region_id STRING COMMENT 'region foreign key',
  product_id STRING COMMENT 'product foreign key',
  channel_id STRING COMMENT 'channel foreign key',
  amount DECIMAL(18,2) COMMENT 'sales amount',
  quantity INT COMMENT 'sales quantity'
) PARTITIONED BY (dt) STORED AS PARQUET;

-- Dimension table: Region
CREATE TABLE dim_region (
  region_id STRING PRIMARY KEY,
  region_name STRING,
  province STRING,
  city STRING
) STORED AS ORC;

-- Dimension table: Product
CREATE TABLE dim_product (
  product_id STRING PRIMARY KEY,
  product_name STRING,
  category STRING,
  brand STRING
) STORED AS ORC;

-- Dimension table: Channel
CREATE TABLE dim_channel (
  channel_id STRING PRIMARY KEY,
  channel_name STRING,
  channel_type STRING
) STORED AS ORC;

2. Model Definition

Create Model in Kylin Web UI:

Fact table: fact_sales
Dimension tables: dim_region, dim_product, dim_channel
Partition field: dt (date)
Measures: SUM(amount), SUM(quantity), COUNT(*)

3. Cube Design

Dimension Config

Dimension Type	Field	Config
Mandatory	dt	Mandatory dimension, all queries include
Hierarchy	dim_region.province, dim_region.city	Hierarchy dimension
Joint	dim_channel	Joint dimension
Normal	dim_product.category, dim_product.brand	Normal dimension

Aggregation Group

Group 1: dt, region_id (high-frequency combination) Group 2: dt, product_id (product analysis) Group 3: dt, channel_id (channel analysis)

Cube Build

Full Build

# Build via Kylin Web UI or REST API
curl -X PUT --user ADMIN:KYLIN \
  -H "Content-Type:application/json;charset=utf-8" \
  -d '{"startTime":"","endTime":"","buildType":"BUILD"}' \
  http://h122.wzk.icu:7070/kylin/api/cubes/ecommerce_cube/build

Build Flow

Step 1: Extract Fact Table - Read Hive fact table
Step 2: Build Dimension Dictionary - Build dimension dictionary
Step 3: Build Cube - Compute each Cuboid
Step 4: Convert Cube to HBase - Convert to HBase storage
Step 5: Checkpoint - Metadata persistence

Query Examples

SQL Queries

-- Sales by date + region
SELECT dt, region_name, SUM(amount) AS total_amount
FROM fact_sales
JOIN dim_region ON fact_sales.region_id = dim_region.region_id
WHERE dt >= '2024-01-01' AND dt <= '2024-01-31'
GROUP BY dt, region_name;

-- Monthly summary by product category
SELECT SUBSTR(dt, 1, 7) AS month, category,
       SUM(amount) AS total, COUNT(*) AS orders
FROM fact_sales
JOIN dim_product ON fact_sales.product_id = dim_product.product_id
GROUP BY SUBSTR(dt, 1, 7), category
ORDER BY month, total DESC;

Query Hit Analysis

View via Kylin Query page:

Hit Cuboid: Which pre-computed Cuboid was used
Query Time: Whether completed in millisecond level
Scan Rows: Number of rows scanned in HBase

Real-time OLAP (Kafka)

Kylin 4.0 supports Kafka real-time stream intake:

Create Streaming Cube: Select Kafka as data source
Configure message format: JSON/Avro
Set time window: Incremental build interval (minute level)
Query: Same syntax as offline Cube query

{
  "dimensions": {"region": "APAC", "product": "phone"},
  "metrics": {"revenue": 12500, "orders": 42},
  "timestamp": "2024-01-15T10:30:00Z"
}

Error Quick Reference

Symptom	Root Cause Location	Fix
Build fails, dimension table primary key duplicate	Dimension table has duplicate primary keys	Preprocess dedup, ensure primary key unique
Build extremely slow, too many Cuboids	Aggregation Group not configured	Split aggregation groups, configure mandatory/hierarchy dimensions
Query misses, falls back to Hive	Query dimension combination not pre-computed	Add Cuboid or adjust query
HBase storage expansion >1000%	High cardinality dimensions + no pruning	Use dictionary encoding, optimize dimension combinations
Real-time build latency high	Kafka consumption lag	Adjust batch processing parameters, increase concurrency
Dimension table OOM	Dimension table too large (>300MB)	Split dimension table, reduce column count
