Apache Druid + Kafka Real-time Analysis: JSON Flattening ...

TL;DR

Scenario: E-commerce clicks/orders flow into Kafka, Druid performs real-time analysis and visualization.
Conclusion: Nested JSON needs preprocessing to flatten; Kafka Indexing Service set “from earliest offset” and disable Rollup is more stable.
Output: Scala Producer→Druid ingestion→SQL metrics (orders/users/payment/TopN) runs through and common pitfalls list.

Overall Process

Kafka Data Source: Kafka is a distributed stream processing platform, responsible for receiving, storing and transmitting data. It supports collecting real-time data from various applications, logs, sensors, etc., divides data into multiple Topics, and distributes messages to consumers.
Kafka Producer: Data producer (Producer) responsible for sending data to Kafka topics.
Druid Kafka Ingestion: Druid provides native support for Kafka. Through Kafka Indexing Service, Druid can continuously consume data from a Kafka topic and ingest into Druid in real-time.
Real-time Data Ingestion and Indexing: Druid’s Kafka ingestion task monitors Kafka partitions, consumes data in order of arrival, and creates indexes internally.
Druid Query Layer: Druid provides very powerful query capability, can query via SQL, also supports multi-dimensional queries, aggregation queries, etc.
Kafka Consumer Offset Management: Druid uses Kafka consumer model, consumes messages in real-time and manages Offsets to ensure no data loss or duplicate ingestion.
Persistence and Data Storage: After ingestion and indexing, Druid periodically persists Segments to deep storage and merges/compresses old data.

Requirements Analysis

Scenario Analysis

Large data volume, need flexible queries based on business needs
High real-time requirement
Data pushed in real-time, need to analyze at second level and query results

Data Description

Original nested JSON data format:

{"ts":1607499629841,"orderId":"1009388","userId":"807134","orderStatusId":1,"orderStatus":"已支付","payModeId":0,"payMode":"微信","payment":"933.90","products":
[{"productId":"102163","productName":"贝合xxx+粉","price":18.7,"productNum":3,"categoryid":"10360","catname1":"厨卫清洁、纸制用品","catname2":"生活日用","catname3":"浴室用品"},{"productId":"100349","productName":"COxxx0C","price":877.8,"productNum":1,"categoryid":"10302","catname1":"母婴、玩具乐器","catname2":"西洋弦乐器","catname3":"吉他"}]}

Field description:

ts: Transaction time
orderId: Order number
userId: User ID
orderStatusId: Order status ID
orderStatus: Order status 0-11
payModeId: Payment method ID
payMode: Payment method
payment: Payment amount
products: Purchased products (nested structure)

Flattened Data Format

{"ts":1607499629841,"orderId":"1009388","userId":"807134","orderStatusId":1,"orderStatus":"已支付","payModeId":0,"payMode":"微信","payment":"933.90","product":
{"productId":"102163","productName":"贝合xxx+粉","price":18.7,"productNum":3,"categoryid":"10360","catname1":"厨卫清洁、纸制用品","catname2":"生活日用","catname3":"浴室用品"}}
{"ts":1607499629841,"orderId":"1009388","userId":"807134","orderStatusId":1,"orderStatus":"已支付","payModeId":0,"payMode":"微信","payment":"933.90","product":
{"productId":"100349","productName":"COxxx0C","price":877.8,"productNum":1,"categoryid":"10302","catname1":"母婴、玩具乐器","catname2":"西洋弦乐器","catname3":"吉他"}}

Kafka Producer

Scala Kafka Producer code example:

package icu.wzk.kafka

import org.apache.kafka.clients.producer.{KafkaProducer, ProducerConfig, ProducerRecord}
import org.apache.kafka.common.serialization.StringSerializer

import java.util.Properties
import scala.io.BufferedSource

object KafkaProducerForDruid {
  def main(args: Array[String]): Unit = {
    val brokers = "h121.wzk.icu:9092"
    val topic = "druid2"
    val prop = new Properties()
    prop.put(ProducerConfig.BOOTSTRAP_SERVERS_CONFIG, brokers)
    prop.put(ProducerConfig.KEY_SERIALIZER_CLASS_CONFIG, classOf[StringSerializer])
    prop.put(ProducerConfig.VALUE_SERIALIZER_CLASS_CONFIG, classOf[StringSerializer])

    val producer = new KafkaProducer[String, String](prop);
    val source: BufferedSource = scala.io.Source.fromFile("orders1.json")
    val iter: Iterator[String] = source.getLines();
    iter.foreach {
      line => val msg = new ProducerRecord[String, String](topic, line);
        producer.send(msg)
        println(msg)
        Thread.sleep(10)
    }
    producer.close()
    source.close()
  }
}

Druid Import Data

Key steps:

Flatten JSON data
Don’t define RollUp
Set timestamp
Set “consume data from start of stream”

Query Calculation

Total Orders

-- Query total orders
SELECT COUNT(distinct orderId) as orderscount
FROM druid2

Total Users

-- Query total users
SELECT COUNT(distinct userId) as usercount
FROM druid2

Order Count by Status

-- Count orders by status
SELECT orderStatus, count(*)
FROM (
  SELECT orderId, orderStatus
  FROM druid2
  GROUP BY orderId, orderStatus
)
GROUP BY orderStatus

Order Count by Payment Method

-- Count orders by payment method
SELECT payMode, count(1)
FROM (
  SELECT orderId, payMode
  FROM druid2
  GROUP BY orderId, payMode
)
GROUP BY payMode

Top 10 Orders by Amount

-- Top 10 orders by amount
SELECT orderId, payment, count(1) as productcount, sum("product.productNum") as products
FROM druid2
GROUP BY orderId, payment

Case Summary

When configuring ingestion source, set to True to consume data from start of stream, otherwise may not find data in datasource
Druid’s JOIN capability is very limited, recommended for scenarios with many groupings or aggregations
SQL support capability is very limited
Data partition organization only has one way: time series

Error Quick Reference

Symptom	Root Cause Location	Fix
Druid table no data/very little consumption	Offset starts from latest, historical not scanned	Set useEarliestOffset: true in ingestion spec, rerun task
Time filter finds no data	ts unit/timezone mismatch	Calibrate timestampSpec (format/timezone/unit)
Numeric column treated as string	JSON field type inconsistent	Unify type in preprocessing; or set correct type in Druid schema
Count result abnormal	Rollup enabled/misused	Turn off Rollup analysis
Order count not equal to row count	Each product split into rows causing duplicate orderId	COUNT(DISTINCT orderId)
Ingestion task stuck PENDING	MiddleManager/Indexer resource slots insufficient	Expand task slots or reduce concurrency
Kafka Lag continuously rising	Task concurrency < partition count	Task count ≥ partition count
Query timeout	Segments too fragmented/Historical node pressure high	Adjust segmentGranularity, merge segments
Time column empty or all 1970	Time parsing failed	Fix time format or unit (ms/seconds)
Too many dimensions causing slow	High-cardinality dimensions not optimized	Enable index/dictionary compression for high-cardinality dimensions
SQL multi-value aggregation error	Multi-value column using unsupported aggregation	Use array_length/UNNEST
Task frequent restart	Offsets commit/group ID config improper	Fix consumerProperties and group ID
