Basic Introduction

Process of Apache Druid获取数据并进行分析 from Kafka:

  1. Kafka Data Flow Ingestion: Druid directly ingests real-time streaming data from Kafka through Kafka Indexing Service
  2. Data Parsing & Transformation: Supports JSON, Avro, CSV formats, can do field mapping, filtering and data transformation
  3. Real-time Data Ingestion & Indexing: Data goes into real-time index, generates inverted index and bitmap index
  4. Batch & Historical Data Merge: Supports real-time and batch hybrid mode
  5. Data Sharding & Replica Management: Supports horizontal scaling, ensures high availability
  6. Query & Analysis: Based on HTTP/JSON API, supports time series queries, grouped aggregation queries, etc.
  7. Visualization & Monitoring: Can integrate with BI tools like Superset, Tableau

Load Data from Kafka

Test Data Example

{"ts":"2020-10-01T00:01:35Z","srcip":"6.6.6.6", "dstip":"8.8.8.8", "srcport":6666,"dstPort":8888, "protocol": "tcp", "packets":1, "bytes":1000, "cost": 0.1}
{"ts":"2020-10-01T00:01:36Z","srcip":"6.6.6.6", "dstip":"8.8.8.8", "srcport":6666,"dstPort":8888, "protocol": "tcp", "packets":2, "bytes":2000, "cost": 0.1}
{"ts":"2020-10-01T00:01:37Z","srcip":"6.6.6.6", "dstip":"8.8.8.8", "srcport":6666,"dstPort":8888, "protocol": "tcp", "packets":3, "bytes":3000, "cost": 0.1}

Configuration Steps

  1. Start Kafka:

    kafka-server-start.sh /opt/servers/kafka_2.12-2.7.2/config/server.properties

  2. Create Topic:

    kafka-topics.sh --create --zookeeper h121.wzk.icu:2181 --replication-factor 1 --partitions 1 --topic druid1

  3. Data Ingestion Process:

    • LoadData → Streaming → Kafka
    • Configure Parser, select JSON format, Parser Time (timestamp maps to __time)
    • Configure timestamp
    • Configuration Schema configures dimensions and metrics:
      • Dimensions: srcip, dstip, srcport, dstport, protocol
      • Metrics: count, max(packets), min(bytes), sum(cost)
    • Partition config: uniform daily partitioning
    • Submit to create Supervisor

Data Query

SELECT * FROM "druid1"

Error Quick Reference

SymptomRoot CauseSolution
Parse preview empty/all nullJSON field names inconsistent with SchemaUse column flattening/transform for alias mapping
Supervisor running but Datasource doesn’t appearKafka has no data or offset start point wrongSet useEarliestOffset=true or reset offset
SQL returns 0 rowsTime parsing error or outside query rangeConfirm ts is ISO8601 format with Z
Cannot parse timestampts format non-compliantUnify time format, specify format
Unknown field in aggregatorsAggregator doesn’t match column typeUse longSum/doubleSum/max/min to match actual type
Low traffic but generates many segmentsSecondary threshold too smallIncrease maxRowsPerSegment
