ClickHouse Sharding × Replica × Distributed: ReplicatedMe...

Replica

Replica refers to storing the same data on different physical nodes in a distributed system. Its core idea is to improve system reliability through data redundancy.

Core Advantages

1. High Availability: When a node experiences hardware failure, network partition, or software crash, other replica nodes can immediately take over
2. Load Balancing: Read requests can be intelligently routed to different replica nodes
3. Data Security: Prevents single point of data loss

Technical Implementation

In ClickHouse, replica mechanism is implemented through collaboration of:

• ReplicatedMergeTree Engine: Base table engine with built-in replica sync logic
• ZooKeeper/Keeper Coordination Service: Stores replica metadata and sync status

Configuration Example

<!-- config.xml -->
<remote_servers>
    <cluster_3shards_3replicas>
        <shard>
            <replica>
                <host>ch01</host>
                <port>9000</port>
            </replica>
        </shard>
    </cluster_3shards_3replicas>
</remote_servers>

Create replicated table:

CREATE TABLE metrics (
    timestamp DateTime,
    value Float64
) ENGINE = ReplicatedMergeTree(
    '/clickhouse/tables/{shard}/metrics',
    '{replica}'
)
ORDER BY timestamp;

Distributed Table

Distributed table is a special table type that doesn’t directly store data, but forwards queries to multiple shard or replica tables.

Distributed(cluster_name, database, table [, sharding_key])

Sharding, Replica and Distributed Table Combination

• Sharding: Through sharding, cluster can scale horizontally
• Replica: Through replica, cluster achieves high availability
• Query Strategy: Queries are usually executed through Distributed table, ClickHouse automatically selects a replica to read data

Configuration File

<yandex>
  <remote_servers>
    <perftest_3shards_1replicas>
      <shard>
        <internal_replication>true</internal_replication>
        <replica>
          <host>h121.wzk.icu</host>
          <port>9000</port>
          <user>default</user>
          <password>clickhouse@wzk.icu</password>
        </replica>
      </shard>
    </perftest_3shards_1replicas>
  </remote_servers>
  <zookeeper-servers>
    <node index="1">
      <host>h121.wzk.icu</host>
      <port>2181</port>
    </node>
  </zookeeper-servers>
  <macros>
    <shard>01</shard>
    <replica>h121.wzk.icu</replica>
  </macros>
</yandex>

Demo

Create Local Table

CREATE TABLE test_tiny_log(
  id UInt16,
  name String
) ENGINE = TinyLog;

Create Distributed Table

CREATE TABLE dis_table(
  id UInt16,
  name String
) ENGINE = Distributed(perftest_3shards_1replicas, default, test_tiny_log, id);

Insert Data

INSERT INTO dis_table SELECT * FROM test_tiny_log;

Query Data

select count() from dis_table;

Error Quick Reference

Symptom/Error	Common Root Cause	Quick Fix
Table doesn’t exist on replica	ON CLUSTER not executed	Add CREATE … ON CLUSTER
ZooKeeper session expired	ZK/Keeper flapping	Troubleshoot network/increase timeout
Too many parts	Too many small parts	Increase batch size/adjust merge threshold
Not enough quorums to write	insert_quorum requirement too high	Lower insert_quorum
Readonly replica	Disk full/readonly	Clear disk/remove readonly
