Replica Introduction

ReplicatedMergeTree ZooKeeper: Implements communication between multiple instances.

Replica Characteristics

As the primary carrier for data replicas, ReplicatedMergeTree has some design considerations:

ZooKeeper Dependency: When executing INSERT and ALTER queries, ReplicatedMergeTree needs ZooKeeper’s distributed coordination to achieve synchronization between replicas. However, ZooKeeper is not required when querying replicas.
Table-level Replicas: Replicas are defined at the table level, so each table’s replica configuration can be customized based on actual needs, including number of replicas and their distribution in the cluster.
Multi Master Architecture: INSERT and ALTER queries can be executed on any replica, they have the same effect. These operations are distributed to each replica for local execution via ZooKeeper coordination.
Block Data Blocks: When writing data with INSERT command, data is split into several Block data blocks based on max_block_size (default 1048576 rows). Block data blocks are the basic unit of data writing, with atomicity and uniqueness.
Atomicity: During data writing, data within a Block either all succeeds or all fails.
Uniqueness: When writing a Block data block, hash digest is calculated and recorded based on data order, rows, and size within the Block. If a Block to be written has the same hash digest as a previously written Block (same data order, size, and rows), that Block is ignored. This design prevents duplicate Block writes caused by exceptions.

ZK Configuration

<yandex>
  <zookeeper-servers>
    <node index="1">
      <host>h121.wzk.icu</host>
      <port>2181</port>
    </node>
    <node index="2">
      <host>h122.wzk.icu</host>
      <port>2181</port>
    </node>
    <node index="3">
      <host>h123.wzk.icu</host>
      <port>2181</port>
    </node>
  </zookeeper-servers>
</yandex>

Enable ZK

Need to enable in config file:

vim /etc/clickhouse-server/config.xml

# Add the following line where you configured before
<include_from>/etc/clickhouse-server/config.d/metrika.xml</include_from>
# If you didn't have the following line before
<zookeeper incl="zookeeper-servers" optional="true" />

Restart Service

systemctl restart clickhouse-server

Verify

-- Connect to ClickHouse
clickhouse-client -m --host h121.wzk.icu --port 9001 --user default --password clickhouse@wzk.icu

-- Check if successfully connected to ZooKeeper
SELECT * FROM system.zookeeper WHERE path = '/';

Replica Definition

Create New Table

CREATE TABLE replicated_sales_5(
  `id` String,
  `price` Float64,
  `create_time` DateTime
) ENGINE = ReplicatedMergeTree('/clickhouse/tables/01/replicated_sales_5', 'h121.wzk.icu')
PARTITION BY toYYYYMM(create_time)
ORDER BY id;

/clickhouse/tables - conventional path
/01/ - shard number
replicated_sales_5 - table name, recommend same as physical table
h121.wzk.icu - replica name in ZK, conventionally server name

ReplicatedMergeTree Principle

Data Structure

[zk: localhost:2181(CONNECTED) 7] ls /clickhouse/tables/01/replicated_sales_5
[alter_partition_version, block_numbers, blocks, columns, leader_election, log, metadata, mutations, nonincrement_block_numbers, part_moves_shard, pinned_part_uuids, quorum, replicas, table_shared_id, temp, zero_copy_hdfs, zero_copy_s3]

Metadata:

metadata: Metadata - primary key, sampling expression, partition key
columns: Column field data types and names
replicas: Replica names

Flags:

leader_election: Master replica election path
blocks: Hash value (duplicate data insertion), partition_id
max_insert_block_size: 1048576 rows
block_numbers: Block order within same partition
quorum: Number of replicas

Operations:

log: log-000000 - regular operations
mutations: delete update

Create Table 1

CREATE TABLE a1(
  id String,
  price Float64,
  create_time DateTime
) ENGINE = ReplicatedMergeTree('/clickhouse/tables/01/a1', 'h121.wzk.icu')
PARTITION BY toYYYYMM(create_time)
ORDER BY id;

Initialize all ZK nodes based on zk_path
Register own replica instance under replicas node
Start listening task, listen to LOG node
Participate in replica election, elect master replica - first to insert becomes master

Create Table 2

Create second replica instance:

clickhouse-client -m --host h122.wzk.icu --port 9001 --user default --password clickhouse@wzk.icu

CREATE TABLE a1(
  id String,
  price Float64,
  create_time DateTime
) ENGINE = ReplicatedMergeTree('/clickhouse/tables/01/a1', 'h122.wzk.icu')
PARTITION BY toYYYYMM(create_time)
ORDER BY id;

At this point participate in replica election, h121.wzk.icu becomes master replica.

Insert Data 1

insert into table a1 values('A001',100,'2024-08-20 08:00:00');

View Results

After execution, view data on ZK:

ls /clickhouse/tables/01/a1/blocks

Output shows: After insert command executes, local partition directory is written, then write block_id for that partition:

[zk: localhost:2181(CONNECTED) 6] ls /clickhouse/tables/01/a1/blocks
[202408_16261221490105862188_1058020630609096934]

View Logs

Next, h121.wzk.icu replica initiates push of operation log to LOG:

[zk: localhost:2181(CONNECTED) 7] ls /clickhouse/tables/01/a1/log
[log-0000000000]

Insert another piece of data:

insert into table a1 values('A002',200,'2024-08-21 08:00:00');

View LOG:

ls /clickhouse/tables/01/a1/log
get /clickhouse/tables/01/a1/log/log-0000000000
get /clickhouse/tables/01/a1/log/log-0000000001

Output:

[zk: localhost:2181(CONNECTED) 14] ls /clickhouse/tables/01/a1/log
[log-0000000000, log-0000000001]

[zk: localhost:2181(CONNECTED) 13] get /clickhouse/tables/01/a1/log/log-0000000000
format version: 4
create_time: 2024-08-01 17:10:35
source replica: h121.wzk.icu
block_id: 202408_16261221490105862188_1058020630609096934
get
202408_0_0_0
part_type: Compact

[zk: localhost:2181(CONNECTED) 16] get /clickhouse/tables/01/a1/log/log-0000000001
format version: 4
create_time: 2024-08-01 17:16:37
source replica: h121.wzk.icu
block_id: 202408_3260633639629896920_11326802927295833243
get
202408_1_1_0
part_type: Compact

Pull Logs

Next, second replica pulls LOG: h122.wzk.icu node always monitors /log node changes. When h121.wzk.icu pushes /log/log-0000, 0001, h122.wzk.icu triggers log pull task and updates log_pointer.

Error Quick Reference

Symptom	Root Cause	Location	Fix
Not connected to ZooKeeper	ZK address/permission/network	telnet zk 2181 / system.zookeeper	Fix config, firewall, restart
Long-time absolute_delay > 0	Slow log pulling/backlog	system.replication_queue	SYSTEM SYNC REPLICA; check disk/CPU
Replica … already exists	Duplicate registration	system.replicas	DROP/DETACH then ATTACH or change {replica}
Too many parts read-only	Too many small parts	system.parts	Adjust batch/merge strategy, reduce write fragmentation
Transaction/DDL inconsistent	DDL not executed on all replicas	system.query_log	Always use ON CLUSTER or cluster_all_replicas=1
