Hive DDL and DML Operations

This is article 13 in the Big Data series. Systematically introduces Hive DDL and DML operations including database management, internal/external table creation, data loading and querying.

Complete illustrated version: CSDN Original | Juejin

Start Hive

hive          # Enter interactive CLI
# or
hiveserver2   # Start HiveServer2 service (for JDBC connections)

DDL — Database Operations

Create Database

-- Default path: /user/hive/warehouse/mydb.db
CREATE DATABASE IF NOT EXISTS mydb;

-- Specify HDFS storage path
CREATE DATABASE IF NOT EXISTS mydb
LOCATION '/user/custom/mydb';

Switch and View Database

USE mydb;
SHOW DATABASES;
DESCRIBE DATABASE mydb;

Delete Database

-- Only delete empty database
DROP DATABASE mydb;

-- Cascade delete (including all tables)
DROP DATABASE mydb CASCADE;

DDL — Table Operations

Internal Table (Managed Table)

Data managed by Hive, DROP TABLE deletes both data and metadata:

CREATE TABLE IF NOT EXISTS emp (
  id      INT,
  name    STRING,
  salary  FLOAT,
  dept    STRING
)
ROW FORMAT DELIMITED
FIELDS TERMINATED BY ','
STORED AS TEXTFILE;

External Table (External Table)

Data stored outside Hive, DROP TABLE only deletes metadata, HDFS data preserved:

CREATE EXTERNAL TABLE IF NOT EXISTS emp_ext (
  id      INT,
  name    STRING,
  salary  FLOAT,
  dept    STRING
)
ROW FORMAT DELIMITED
FIELDS TERMINATED BY ','
LOCATION '/user/hadoop/empdata';

Usage Suggestion: Prefer external tables in production to prevent accidental data deletion.

Internal Table vs External Table

Feature	Internal Table	External Table
Data Management	Hive manages	User manages
DROP Behavior	Deletes data + metadata	Only deletes metadata
Data Location	warehouse directory	Custom LOCATION
Applicable Scenario	Temporary tables, intermediate results	Production data, shared data

View and Modify Table

SHOW TABLES;
DESCRIBE emp;           -- View column info
DESCRIBE FORMATTED emp; -- View detailed info (storage format, HDFS path)

-- Rename
ALTER TABLE emp RENAME TO employee;

-- Add columns
ALTER TABLE emp ADD COLUMNS (email STRING);

Delete Table

DROP TABLE IF EXISTS emp;
TRUNCATE TABLE emp;  -- Only clear data, keep table structure (internal tables only)

DML — Data Operations

Load Local File

-- Load from local filesystem (MOVE, original file not deleted)
LOAD DATA LOCAL INPATH '/home/hadoop/emp.csv' INTO TABLE emp;

-- Overwrite load
LOAD DATA LOCAL INPATH '/home/hadoop/emp.csv' OVERWRITE INTO TABLE emp;

Load from HDFS

-- Load from HDFS (MOVE, original HDFS file is moved)
LOAD DATA INPATH '/user/hadoop/emp.csv' INTO TABLE emp;

INSERT

-- Single record
INSERT INTO TABLE emp VALUES (1, 'Tom', 5000.0, 'Engineering');

-- Insert from query result
INSERT INTO TABLE emp_high_salary
SELECT * FROM emp WHERE salary > 8000;

-- Overwrite
INSERT OVERWRITE TABLE emp_copy
SELECT * FROM emp;

Multi-table Insert (One Scan, Multiple Writes)

FROM emp
INSERT INTO TABLE high_salary  SELECT * WHERE salary > 8000
INSERT INTO TABLE low_salary   SELECT * WHERE salary <= 8000;

This approach only needs to scan source table once, significantly reducing MapReduce job count.

CTAS (Create Table As Select)

CREATE TABLE emp_copy AS SELECT * FROM emp;

DQL — Query Operations

-- Basic query
SELECT id, name, salary FROM emp WHERE dept = 'Engineering';

-- Sort and pagination
SELECT * FROM emp ORDER BY salary DESC LIMIT 10;

-- Aggregation statistics
SELECT dept,
       COUNT(*)   AS cnt,
       AVG(salary) AS avg_sal,
       MAX(salary) AS max_sal
FROM emp
GROUP BY dept
HAVING COUNT(*) > 3;

-- JOIN query
SELECT a.name, b.dept_name
FROM emp a
JOIN dept b ON a.dept = b.dept_id;

Hive Utility Commands

-- Execute Shell commands in Hive CLI
!ls /home/hadoop;
!clear;

-- Execute HDFS commands in Hive CLI
dfs -ls /user/hive/warehouse;
dfs -mkdir /user/test;

-- View built-in function list
SHOW FUNCTIONS;

-- View function usage
DESCRIBE FUNCTION substr;

Common hive-site.xml Configuration

<!-- Use local mode for small datasets, skip YARN submission, speed up debugging -->
<property>
  <name>hive.exec.mode.local.auto</name>
  <value>true</value>
</property>

<!-- CLI prompt shows current database -->
<property>
  <name>hive.cli.print.current.db</name>
  <value>true</value>
</property>

<!-- Query results show column names -->
<property>
  <name>hive.cli.print.header</name>
  <value>true</value>
</property>

After enabling local mode, queries on small datasets run directly in client JVM without submitting YARN jobs, significantly improving query speed—suitable for development and debugging.
