消费者模块

从配置到代理

  • 解析配置：ReferenceConfig, DubboBootstrap，读取配置并合并
  • 注册中心订阅：RegistryDirectory，向 Nacos/ZooKeeper 订阅服务列表
  • 目录路由：RouterChain，根据规则对 Provider 列表过滤
  • 集群封装：Cluster, ClusterInvoker，实现容错机制
  • 负载均衡：LoadBalance，支持 Random/RoundRobin/ConsistentHash/LeastActive
  • 动态代理：ProxyFactory，生成本地代理类
  • 连接池 & 网络：ExchangeClient（Netty），支持 Triple/Dubbo 协议

运行时调用链

业务代码 → 接口代理 → Filter 链 → ClusterInvoker
             ↓                 ↓
          Async/Future      LoadBalance
             ↓                 ↓
       ExchangeClient → Netty → Provider

关键扩展点（SPI）

  • Filter：ExceptionFilter, TraceFilter, SentinelFilter
  • Cluster：Failover, Failfast, Broadcast, Forking
  • LoadBalance：Random, RoundRobin, LeastActive, ConsistentHash

POM 依赖

<dependencies>
    <dependency>
        <groupId>icu.wzk</groupId>
        <artifactId>wzk-service-api</artifactId>
    </dependency>
</dependencies>

消费者定义

@Component
public class ConsumerComponent {
    @Reference
    private WzkHelloService wzkHelloService;

    public String sayHello(String name) {
        return wzkHelloService.sayHello(name);
    }
}

配置文件

dubbo.application.name=service-consumer
dubbo.registry.address=zookeeper://10.10.52.38:2181

启动类

生产者启动

public class DubboPureMain {
    public static void main(String[] args) throws Exception {
        AnnotationConfigApplicationContext context =
                new AnnotationConfigApplicationContext(ProviderConfiguration.class);
        context.start();
        System.in.read();
    }
}

消费者启动

public class AnnotationConsumerMain {
    public static void main(String[] args) throws Exception {
        AnnotationConfigApplicationContext context =
                new AnnotationConfigApplicationContext(ConsumerConfiguration.class);
        context.start();

        ConsumerComponent service = context.getBean(ConsumerComponent.class);
        while (true) {
            try {
                String hello = service.sayHello("world!");
                System.out.println("result: " + hello);
                Thread.sleep(3000);
            } catch (Exception e) {
                e.printStackTrace();
            }
        }
    }
}

高频配置参数

参数说明
timeoutRPC 调用超时时间 (ms)
retries失败重试次数
check启动时是否校验 Provider 存在
lazy首次调用时才创建连接
cache开启本地方法缓存
mock服务降级策略
async是否异步调用
